KGB100B yog ib tus neeg sib tw rau cov khoom loj hollow tsuas yog thaum qhov chaw, pwm, tag nrho parison thiab Hoobkas tag nrho haum nws cov kev txwv luam tawm. Kinggle teev 120 L siab kawg ntim ntim, 920 x 1200 mm siab tshaj pwm loj, 12 (20) L accumulator siv thiab 9 (15) kg PE accumulator-qhov hnyav siv. Cov nuj nqis no pib qhov kev tshuaj xyuas engineering, tab sis cov khoom kos duab thiab cov phiaj xwm sim yuav tsum daws qhov kev xaiv zaum kawg.
Tus neeg yuav khoom nrhiav 120L tshuab moulding tshuab feem ntau muaj qhov tseeb hauv siab. Tej zaum nws yuav yog ib lub nruas, tsheb thauj mus los, float, tank, khoom ua si lossis cov khoom siv loj. Daim ntawv ntim khoom siv tau zoo, tab sis nws tsis piav txog qhov nyuaj tshaj plaws, kev txav pwm, kev faib phab ntsa lossis qhov xav tau txias.
Phau ntawv no nyeem KGB100B raws li kev tsim khoom. Nws piav qhia tias txhua tus lej luam tawm tuaj yeem qhia koj li cas thiab nws ua tsis tau. Nws kuj tseem qhia tau tias yuav xa dab tsi nrog RFQ, yog li kev sib tham tuaj yeem txav los ntawm lub npe tshuab dav dav mus rau qhov kev daws teeb meem.
Rau lo lus nug rau kev kuaj xyuas khoom sai
- Puas yog cov pwm ua tiav haum rau lub platen, pwm lub hnab ntawv thiab thickness ntau?
- Cov cua txias puas tuaj yeem tawm hauv pwm los ntawm qhov qhib qhib?
- Puas yog tag nrho parison pawg nyob rau hauv cov xaiv accumulator configuration?
- Lub extruder puas tuaj yeem rov qab tau cov khoom txaus rau lub hom phiaj?
- Lub zog clamp puas tuaj yeem muaj qhov pom zoo qhov projected thiab tshuab siab?
- Cov nroj tsuag puas tuaj yeem muab lub zog ruaj khov, dej txias thiab cua compressed?
Specification ciam teb:cov duab hauv phau ntawv qhia no yog los ntawm tam sim noKinggle KGB100B khoom nplooj. Lawv raug kuaj xyuas thaum lub Cuaj Hlis 15, 2026. Ua rau lawv raws li cov ntaub ntawv soj ntsuam luam tawm. Kev pom zoo hais, layout, tshuab kos duab thiab kev pom zoo yuav tsum txhais lub tshuab txiav txim.
Daim ntawv lo 120L yog qhov pib, tsis pom zoo rau cov khoom
Kinggle luam tawm 120 L raws li KGB100B lub peev xwm siab tshaj plaws. Qhov ntawd ua rau cov neeg yuav khoom tau nrawm nrawm. Nws tsis tau hais tias txhua qhov qis dua 120 L yuav khiav ntawm lub tshuab. Lub nruas compact thiab lub tsheb thauj mus ntev ntev tuaj yeem muaj qhov sib txawv pwm dav, thaj chaw npaj, parison lengths thiab kev tshem tawm.
Nominal ntim tuaj yeem zais cov khoom xav tau. Qhov loj nyias-walled ntab yuav muaj huab cua ntau dua tab sis tsawg dua li cov khoom siv me me nrog cov tav tuab tuab, tuav thiab pinch zones. Lub tshuab yuav tsum tsim kom tiav cov parison kub, nrog rau cov khoom uas tom qab ua flash los yog trim. Cov khoom tiav qhov hnyav ib leeg yog li understates txhaj tshuaj uas lub taub hau yuav tsum xa.
Geometry hloov qhov kev txiav txim dua. Cov cheeb tsam sib sib zog nqus tuaj yeem ncav cuag parison hnyav. Cov vaj huam sib luag dav yuav xav tau ntau lub zog clamp. Qhov ntev tuaj yeem raug txwv los ntawm kev tuag-rau-pwm deb lossis tshem tawm qhov chaw ua ntej ntim ntim yuav cuam tshuam. Lub caj dab inserts, cov xov sab hauv thiab hauv qab tshuab tuaj yeem ntxiv zog ntxiv rau lub voj voog.
Siv cov lus piav qhia 120L los tsim cov npe luv. Tom qab ntawd sib piv qhov tiag thiab pwm nrog lub tshuab. Qhov no yog vim li cas Kinggle tus kheejkev muag khoomnug cov khoom duab, kos duab, qhov hnyav, qhov loj me, cov khoom siv, thickness thiab cov khoom tsim tawm ua ntej cov qauv pom zoo.
Cov kab ke ntawd khaws lub peev xwm daim ntawv lo rau hauv nws lub luag haujlwm kom raug: kev tshuaj ntsuam sai ua ntej, kev pom zoo engineering thib ob.
Tig KGB100B specification rau hauv cov lus nug ntawm cov neeg yuav khoom
Cov lus qhia tshwj xeeb yog qhov muaj txiaj ntsig zoo tshaj plaws thaum txhua tus lej coj mus kuaj. KGB100B nplooj ntawv npog tshuab loj, clamping, extrusion, lub taub hau accumulator thiab cov ntaub ntawv siv hluav taws xob. Qee qhov txiaj ntsig yog qhov txwv tseeb. Lwm tus piav qhia txog kev teeb tsa kev tshaj tawm lossis lub tshuab tsis muaj lub tshuab.
Nplooj ntawv teev cov accumulator li 12(20) L thiab PE accumulator hnyav li 9(15) kg. Cov kab lus tshwm sim los qhia txog lwm txoj hauv kev, tab sis nplooj ntawv tsis txhais txoj cai xaiv. Cov lus hais yuav tsum yog lub npe ntawm ib lub taub hau kev npaj thiab nws cov khoom siv. Tsis txhob muab cov duab loj dua nrog lub tshuab ua qauv kev xav tshwj tsis yog Kinggle lees paub nws rau qhov project.
| Tshaj tawm teb | KGB100B siv | Lo lus nug nws yuav tsum ua |
|---|---|---|
| Muaj peev xwm ntim siab tshaj plaws | 120 L | Puas yog qhov khoom tiag tiag geometry thiab tag nrho parison haum, tsis yog nws lub npe ntim? |
| Tso zis | 320 pcs / h, lub voj voog qhuav | Cov zis dab tsi tuaj yeem tuav nrog cov pwm tsim, cob, cua txias thiab cov kev cai zoo? |
| Tshuab loj | 5.9 x 3.8 x 4.6 m | Puas muaj chaw txaus rau kev nkag, platforms, hoses, tuav thiab tu? |
| Tshuab hnyav | 18t ib | Lub hauv paus thiab txoj kev npaj rigging dab tsi ua raws li qhov kev npaj ua ntej kawg? |
| Clamping quab yuam | 440kn ua | Puas yog nws txaus rau qhov khoom qhov projected cheeb tsam ntawm qhov pom zoo txheej txheem siab? |
| Platen thiab mold references | 1200 x 1200 hli platen; 920 x 1200 mm siab tshaj pwm | Puas yog lub cev pwm, mounting qauv, kev pabcuam thiab kev sib txuas ua ke? |
| Qhib thiab txav | 500-1400 hli qhib; 600mm txav stroke | Puas tuaj yeem tso tawm thiab tawm yam tsis muaj kev sib tsoo lossis ua kom puas qhov chaw kub? |
| Pwm thickness | 510-600 hli | Puas tau nruab thickness muaj xws li thaub qab daim hlau, adapters thiab yuav tsum tau tooling? |
| Extruder | 100mm ntsia hlau; 24 L / D; 55 kW lub cev muaj zog | Puas yog xaiv cov ntsia hlau thiab cov txheej txheem qhov rais haum rau cov ntaub ntawv teev tseg? |
| Tshaj tawm HDPE melting muaj peev xwm | 160-200 kg / h | Puas yog tag nrho cov khoom xav tau qis dua qhov pov thawj ruaj khov rau qhov tseeb formulation? |
| Accumulator taub hau | 12(20) L; 9 (15) kg PE siv | Qhov kev xaiv twg yog hais, thiab nws puas npog tag nrho parison pawg nrog cov txheej txheem siv tau? |
| Tuag-pin diam | Qhov siab tshaj plaws 450 mm | Dab tsi tuag thiab tooling pob yog xav tau rau lub parison txoj kab uas hla thiab cov khoom layout? |
| Kev siv dej txias-dej | 0.3 MPa; 120L / min | Nyob rau hauv dab tsi inlet kub, dej zoo thiab Circuit Court scope qhov no siv? |
| Tshaj tawm nruab nrab lub zog kab | 52 rau 60 kW | Yam khoom uas cuam tshuam txog kWh / kg thiab kWh ib feem tau txais raug ntsuas thaum lub sijhawm sim ruaj khov? |
Cov nplooj ntawv khoom tseem tshaj tawm 0.8 MPa tshuab siab thiab cov huab cua ntws ntawm 1.8, tab sis nws qhov pom pom tau ua raws li M2 / MIN. Chav tsev ntawd xav tau kev kho lossis kev pom zoo ua ntej nws nkag mus rau qhov chaw tshwj xeeb. Lub luag haujlwm RFQ yuav tsum chij qhov tsis paub tseeb es tsis txhob ua ntsiag to hloov chav tsev.
Nyeem cov kab ntsig ua ke. Pwm loj belongs nrog qhib thiab thickness. Accumulator pawg belongs rau cov resin xaiv thiab tag nrho txhaj tshuaj. Melting muaj peev xwm belongs nrog lub sij hawm rov qab thiab ruaj khov yaj zoo. Tshuab qhov ntev yog nrog kev saib xyuas thiab cov cuab yeej pabcuam. Qhov kev sib txuas nyeem ntawv no txwv tsis pub ib tus lej zoo los ntawm kev zais ib txoj haujlwm sib txawv.
Tshawb xyuas lub hnab ntawv pwm thiab txoj kev tshem tawm ib feem
Qhov tshaj tawm pwm loj yog 920 x 1200 mm. Lub platen yog 1200 x 1200 hli, thiab pwm thickness ntau yog 510 mus rau 600 hli. Cov txiaj ntsig no piav qhia txog qhov ntev, tab sis lawv tsis hloov pauv tau. Lub pwm tuaj yeem haum rau lub ntsej muag qhov ntev thiab tseem tsis sib haum nrog cov hlua khi, cov kav dej, cov qhov txuas lossis cov khoom txav.
Pib nrog kev kos duab sib dhos, tsis yog cov khoom kos duab. Qhia ob lub puab tsaig, nraub qaum daim hlau, dej manifolds, tshuab pins, caj dab lossis hauv qab cov cuab yeej, cov khoom siv hydraulic, sensors thiab lub thawv hluav taws xob. Txheeb xyuas qhov chaw nruab nrab thiab mounting qauv. Kos txhua yam khoom uas txav tawm sab nraud lub cev pwm thaum qhib.
Tom ntej no, simulate tshem tawm. KGB100B nplooj ntawv luam tawm 500 txog 1400 mm platen qhib siv thiab 600 mm platen txav stroke. Qhov tiav lawm xav tau qhov chaw ntshiab kom tso tawm, tig yog tias tsim nyog thiab tawm hauv lub tshuab. Flash, tails, handles thiab kub hloov tau cov phab ntsa tuaj yeem nthuav lub hnab ntawv tshem tawm tiag tiag.
Ib feem tawv kuj tseem ceeb. Ib qho hollow loj tuaj yeem deform yog tias tus neeg hlau tuav nws ua ntej phab ntsa npaj. Ib qho yooj yim poob tuaj yeem ua rau lub caj dab puas los yog tawm ntawm lub cim rau ntawm lub vaj huam sib luag sov. Lub sijhawm txias hauv pwm thiab kev txhawb nqa tom qab ejection yog nyob rau hauv kev tshuaj xyuas layout.
Hoobkas saib:khaws cov pwm kos duab ntawm ib sab ntawm lub tshuab dav dav. Ntxiv cov crane nuv txoj kev, pwm-lub laub txoj kev, kev pab cuam-sab clearance thiab tus neeg teb xov tooj txoj kev nyab xeeb. Cov luam tawm 5.9 x 3.8 x 4.6 m tshuab qhov ntev tsis yog qhov ua tiav ntawm tes taw.
Kev tshuaj xyuas kom zoo kuj suav nrog pwm qhov hnyav thiab nqa cov ntsiab lus, txawm tias nplooj ntawv cov khoom lag luam tsis tshaj tawm cov pwm-qhov hnyav. Nug Kinggle kom paub meej tias qhov hnyav pwm qhov hnyav thiab qhov pom zoo tuav txoj hauv kev rau kev teeb tsa. Covextrusion tshuab moulding pwm tsim kev qhiamuab ib daim ntawv teev tag nrho kom txias, pinch-off thiab venting.
Loj lub accumulator los ntawm tag nrho parison loj
Lub accumulator lub taub hau khw muag khoom yaj thiab thawb tawm ib tug loj parison ntawm kev thov. Cov khoom siv kom muaj nuj nqis yog qhov ua tiav txhaj tshuaj tawm ntawm lub taub hau. Nws suav nrog cov khoom muag, sab saum toj thiab hauv qab flash, kov lossis caj dab seem, thiab lwm yam khoom siv trimmed tsim los ntawm cov cuab yeej xaiv.
Gross parison mass = tiav ib feem pawg + flash thiab trim pawg + tswj txheej txheem nyiaj pub dawb
Cov nyiaj pub dawb tsis yog feem pua ntawm universal. Nws yuav tsum yog los ntawm qhov pom zoo, lub tswv yim pwm, cov khoom siv coj los siv thiab cov txiaj ntsig kev sim.
Kinggle luam tawm 9 (15) kg raws li PE accumulator-qhov hnyav siv rau KGB100B. Qhov ntawd tsis yog kev cog lus tias cov khoom tiav tuaj yeem hnyav 9 lossis 15 kg. Nws tseem tsis tuaj yeem hloov mus rau PP, ABS lossis cov ntawv sau. Resin ceev, yaj lub zog, kub thiab lub taub hau mob cuam tshuam rau cov txheej txheem siv tau.
12 (20) L accumulator peev kab xav tau kev saib xyuas tib yam. Litre muaj peev xwm piav qhia txog qhov ntim hauv qhov system, thaum cov khoom kos duab thiab cov khoom siv feem ntau yog tswj hwm los ntawm pawg. Nug seb lub taub hau kev xaiv twg yog suav nrog, uas cov resin txhawb nqa cov ntawv luam tawm, thiab cov khoom siv ntau npaum li cas tseem nyob hauv lub taub hau ntawm qhov pom zoo ua haujlwm.
Tsis txhob khiav ntawm qhov kev txwv theoretical los ntawm lub neej ntawd. Ib qhov project xav tau kev tswj kom txaus los kho cov phab ntsa faib thiab kev txhaj tshuaj sib txawv. Yog hais tias tag nrho cov parison nyob ze tag nrho cov muaj peev xwm, tom qab ntawd hloov cov khoom siv los yog kev kho thickness hauv zos yuav tshem tawm chav ntawd. Qhov kev sim yuav tsum tau qhia qhov kev txhaj tshuaj ruaj khov, rov ua dua parison ntev thiab siv tau cushion rau lub taub hau xaiv.
Rau ntau qhov pwm, suav txhua parison tso tawm ib lub voj voog. Qhov kev txhaj tshuaj tiav yuav tsum npog txhua qhov hluav taws xob nquag thiab nws cov luas. Lub taub hau suav thiab kab noj hniav suav tuaj yeem hloov pauv lej, yog li qhia lawv cais hauv RFQ. Covtaub hau thiab kab noj hniav qhiapiav qhov txawv ntawd.
Txuas lub extruder rau cov khoom xav tau thiab lub sijhawm rov qab los
KGB100B nplooj ntawv teev cov ntsia hlau 100 hli, 24 L / D piv, 55 kW extruder lub cev muaj zog thiab plaub thaj chaw cua sov. Nws luam tawm HDPE yaj-muaj peev xwm ntawm 160 txog 200 kg / h. Qhov ntau yog cov ntaub ntawv-scoped siv. Nws yuav tsum tsis txhob raug kho raws li ib tug guaranteed tso zis rau txhua qib, masterbatch, regrind piv los yog kub qhov rais.
Hloov lub hom phiaj ntau lawm mus rau tag nrho cov kev thov txhua teev. Siv tag nrho parison pawg, tsis tiav ib feem pawg. suav nrog txhua txoj haujlwm nquag thiab siv cov txheej xwm npaj rau ib teev. Qhov no muab cov khoom siv tus nqi uas lub extruder thiab lub taub hau yuav tsum tau txhawb nqa thaum lub tshuab ua qhov tau txais.
Tag nrho cov khoom xav tau, kg / h = tag nrho parison huab hwm coj ib qho kev tshwm sim, kg x molding txheej xwm ib teev x active parisons ib qhov kev tshwm sim
Sib piv qhov tshwm sim nrog kev sim ntawm qhov tseeb formulation. Ib daim ntawv qhia ib leeg tsis tuaj yeem tsim kom muaj qhov zoo ntawm cov yaj lossis cov npoo rov qab.
Lub sijhawm rov qab yuav tsum haum rau hauv lub voj voog tshuab. Yog tias cov pwm nyob twj ywm kaw kom txias, lub extruder feem ntau siv lub sij hawm ntawd los recharge lub accumulator. Lub voj voog txias luv luv tuaj yeem nce qhov xav tau yaj tus nqi. Cov pwm nrawm nrawm dua muaj nqis me ntsis yog tias lub taub hau tsis tau npaj rau kev txhaj tshuaj tom ntej.
Kev tuav cov khoom tuaj yeem dhau los ua qhov kev txwv zais cia. Cov khoom loj noj cov resin sai sai. Cov nroj tsuag xav tau kev txhim khu kev qha, ziab thaum cov khoom xav tau nws, sib tov thiab tswj kev sib kis. Regrind tuaj yeem hloov ntau qhov ntom ntom thiab pub tus cwj pwm. Ib daim ntawv sau muaj txiaj ntsig zoo dua li daim ntawv lo dav xws li "HDPE ntxiv rau regrind."
Nug cov ntaub ntawv mus sib hais kom suav nrog qib resin, tus neeg muag khoom, cov xim pob, qhov feem pua regrind, qhov ntsuas kub, qhov ceev ceev thiab qhov tseeb tag nrho. Yog tias lwm yam khoom raug npaj, thov cov ntaub ntawv pov thawj tshwj xeeb. Kinggle covHDPE thiab PP txheej txheem qhiapiav qhia tias vim li cas daim ntawv lo polymer ib leeg tsis kho lub tshuab teeb.
Txuas clamp quab yuam, qhov projected cheeb tsam thiab tshuab tshuab
KGB100B nplooj ntawv luam tawm 440 kN ntawm clamping quab yuam. Tus lej loj dua tsis tuaj yeem zoo dua, thiab daim ntawv ntim ntim tsis tuaj yeem lees paub lub clamp. Cov pwm pom kev sib cais quab yuam thoob plaws hauv qhov projected cheeb tsam raug rau sab hauv siab. Cov khoom zoo, flash land, pinch-tawm tsim thiab txheej txheem siab tag nrho cov cuam tshuam qhov yuav tsum tau tiag tiag.
Projected cheeb tsam yog lub silhouette ntawm lub pressurized kab noj hniav ntawm pwm parting dav hlau. Lub tiaj tiaj tiaj tuaj yeem tsim kom muaj kev sib cais ntau dua li qhov sib sib zog nqus tab sis nqaim. Kev tshuaj xyuas yuav tsum siv cov kab noj hniav tiag tiag. Nws tseem yuav tsum suav nrog qhov kev xaiv tshuab siab thiab ib qho kev pom zoo kev nyab xeeb.
Cov nplooj ntawv pej xeem teev 0.8 MPa raws li kev siv tshuab siab. Qhov ntawd tsis txhais hais tias txhua yam khoom yuav tsum khiav ntawm tib qhov chaw. Resin kub, venting, phab ntsa thickness, nto nthuav dav thiab txias lub tswv yim muaj feem xyuam rau cov txheej txheem. Lub Hoobkas sim yuav tsum siv cov ntaub ntawv tsim tawm qhov rais uas tsim cov khoom siv tau yam tsis muaj kev loj hlob flash lossis pwm tsis ruaj khov.
Pinch-off tsim yog ib feem ntawm tib qhov system. Kev sib khi tsis muaj zog tuaj yeem tsim cov xau los yog cov khoom tawg yooj yim. Cov khoom siv ntau dhau tuaj yeem ua kom lub ntsej muag loj dua thiab ua rau kev txiav nyuaj. Pwm dlhos, clamp tsab ntawv tsa suab thiab parison qhov chaw yuav tsum txhawb nqa cov cuab yeej es tsis them nyiaj rau nws.
Nug tus neeg muag khoom pwm thiab lub tshuab xa khoom los tshuaj xyuas tib daim duab. Qhov no tiv thaiv qhov sib txawv uas txhua tog pom zoo tsuas yog nws cov khoom siv xwb. Qhov kawg kev pom zoo yuav tsum tau lub npe projected cheeb tsam, txheej txheem siab, clamp yuav tsum tau, pwm thickness, mounting thiab kev twb kev txuas cov ntsiab lus.
Npaj lub Hoobkas nyob ib ncig ntawm lub cell molding tiav
KGB100B nplooj ntawv luam tawm lub tshuab loj ntawm 5.9 x 3.8 x 4.6 m thiab qhov hnyav ntawm 18 t. Cov no yog cov tseem ceeb pib cov ntsiab lus rau layout thiab rigging. Lawv tsis suav nrog txhua lub platform, resin system, chiller, compressor, tshem tawm cov cuab yeej, conveyor, trimmer lossis thaj tsam kev nyab xeeb.
Pib saum lub tshuab. Paub meej meej lub tsev qhov siab, lub peev xwm crane, kev tshem tawm lub taub hau thiab nkag mus rau cov cua sov thiab cov khoom siv hydraulic. Tom qab ntawd ua haujlwm sab nraud. Cov neeg ua haujlwm xav tau qhov chaw los tshuaj xyuas cov pwm, tshem tawm qhov cuam tshuam thiab ncav cuag cov kev pabcuam qub. Kev xa khoom thiab kev ua tiav tiav yuav tsum muaj txoj hauv kev uas tsis hla thaj chaw tsis muaj kev nyab xeeb.
Cov dej txias tsim nyog ntau tshaj qhov kwv yees qhov loj ntawm cov yeeb nkab. Nplooj ntawv teev 0.3 MPa thiab 120 L / min, tab sis cov nroj tsuag kuj xav tau qhov xav tau qhov kub thiab txias, qhov ntsuas kub tau nce, dej zoo, pom thiab rov qab mob. Pwm circuits thiab roj txias yuav xav tau kev tswj xyuas nyias. Daim ntawv siv hluav taws xob zaum kawg yuav tsum hais txog dab tsi suav nrog hauv cov ntawv luam tawm.
Compressed cua xav tau tib yam kev kho mob. Lub vev xaib muab 0.8 MPa siab siv, tab sis nws pom huab cua ntws tsis sib haum. Thov kom kho lub tshuab-inlet thov, qhov xav tau siab tshaj plaws, huab cua zoo, dew point thiab qhov sib txuas loj. Lub receiver yuav xav tau los ua kom lub siab ruaj khov thaum lub sijhawm tshuab tshuab loj.
Cov nplooj ntawv khoom sau npe 52 txog 60 kW raws li "kev siv hluav taws xob nruab nrab." Vim tias kW yog lub zog hluav taws xob, siv daim duab nkaus xwb raws li kev siv hluav taws xob luam tawm. Tsis txhob hloov mus rau kWh rau ib feem. Cov khoom lag luam ntsig txog lub zog nyob ntawm cov pwm, resin, lub voj voog, cov pab cuam thiab cov khoom siv tau txais.
EUROMAP 46.2txhais cov khoom ntsig txog kev ntsuas rau qhov muab extrusion tshuab moulding tshuab, pwm thiab cov khoom teev. Nws xav tau kev lag luam ruaj khov thiab cov khoom lag luam zoo uas ua tau raws li cov neeg siv khoom xav tau. Qhov no yog lub hauv paus zoo rau qhov kev xeem txais. Kinggle covdaim ntawv qhia txog kev siv hluav taws xobtuaj yeem pab tsim cov ntaub ntawv cog qoob loo.
A 320 pcs / h qhuav voj voog tsis yog cov khoom tsim tawm
Kinggle daim ntawv lo 320 pcs / h raws li KGB100B qhuav-cycle tso zis. Lub voj voog qhuav ntsuas tshuab txav tsis tau ua pov thawj tag nrho cov txheej txheem tsim khoom. Nws tsis suav nrog resin rov qab, parison poob, tshuab, txias, tshem tawm ib feem, trimming los yog kev soj ntsuam zoo nyob rau hauv lub npaj ntau lawm tej yam kev mob.
Qhov loj me feem ntau yog txias-txias. Thick handles, fab thiab pinch zones yuav xav tau sijhawm ntau dua li cov phab ntsa dav. Kev qhib nrawm nrawm tsis tuaj yeem tso ib feem uas tseem mos dhau los tuav cov duab. Automation kuj tuaj yeem teem caij yog tias tus neeg hlau, trimmer lossis conveyor qeeb dua lub tshuab molding.
Siv peb qhov txiaj ntsig tso tawm. Ua ntej, sau lub voj voog qhuav tsuas yog siv cov lus tsa suab. Qhov thib ob, ntsuas tag nrho cov molded qhov chaw hauv ib teev thaum lub sijhawm tsim khoom. Thib peb, tshaj tawm qhov lees txais ib teev tom qab pom zoo kuaj xyuas thiab suav cov nres.
Txais cov zis = tag nrho molded qhov chaw - tsis lees paub qhov chaw - qhov poob thaum suav nres
Rau kev npaj ua haujlwm, sau lub sijhawm ntsuas thiab nres pawg. Kev soj ntsuam luv luv zoo tshaj plaws tsis yog qhov kev tsim khoom ruaj khov.
Txoj kev npaj txais yuav tsum tau lub npe, pwm, resin, xim, regrind txoj cai, tus neeg teb xov tooj ua thiab cov khoom pab. Nws kuj yuav tsum tau txhais cov qauv zoo. Qhov hnyav, qhov ntev, kev ua haujlwm tsis zoo, lub teeb nyem, qhov pom thiab qhov chaw ntawm phab ntsa-thickness yog ntau pawg, tab sis qhov project yuav tsum xaiv qhov tseem ceeb.
Siv lub hom phiaj voj voog raws li pob nyiaj siv. Txiav nws mus rau hauv accumulator tawm, pwm txav, tshuab, txias, tso pa, qhib, tshem tawm thiab rov qab. Qhov no qhia tau hais tias qhov kev txwv yog los ntawm lub tshuab, pwm, khoom siv los yog kev ua haujlwm qis. Covcycle-time optimization phau ntawv qhiapiav qhia yuav ua li cas txhim kho ib theem yam tsis hloov qhov tsis xws luag mus rau lwm qhov.
Phab ntsa programming yuav tsum ua raws li cov khoom, tsis yog ib qho kev sib tw
Loj extrusion tshuab moulded qhov chaw stretch unevenly. Cov khoom nyob ze ntawm lub xub pwg nyom, ces kaum, kov los yog sib sib zog nqus kos tuaj yeem mus deb dua li cov khoom siv ntawm lub vaj huam sib luag dav. Qhov sib txawv ntawm qhov tuag tsis zoo yuav ua rau ib cheeb tsam nyias dhau thaum lwm tus nqa qhov hnyav tsis tsim nyog.
Nplooj ntawv KGB100B hais tias tus qauv qauv suav nrog MOOG 100 thickness controller. Qhov tseeb ntsia maub los, profile daws teeb meem thiab xaiv pob yuav tsum muaj npe nyob rau hauv cov lus hais. AKinggle-hosted Moog DigiPack III phau ntawvqhia tau hais tias yuav ua li cas lub accumulator-tshuab maub los tuaj yeem txuas cov cuab yeej txoj haujlwm mus rau qhov programmed profile. Nws kuj teev cov koob txhaj tshuaj loj, cushion thiab accumulator-txoj haujlwm ua haujlwm. Phau ntawv ntawd qhia txog kev tswj cov logic, tab sis nws yuav tsum tsis txhob siv los xav tias qhov tseeb KGB100B interface.
Tsim thawj qhov profile los ntawm kev paub geometry thiab pwm lub sijhawm. Tom qab ntawd txiav los yog ntsuas qhov chaw ntawm qhov chaw teev tseg. Hloov ib cheeb tsam ntawm ib lub sij hawm thiab sau cov kev hloov kho. Ib qhov hnyav dua tsis tau txais qhov zoo dua. Lub hom phiaj yog cov khoom siv txaus qhov twg qhov kev ua tau zoo xav tau thiab tsawg dua qhov twg nws tsis.
Profile ua hauj lwm yuav tsum nyob twj ywm txuas nrog txhaj koob tshuaj tivthaiv loj thiab parison ntev. Txhim kho ib cheeb tsam profile hloov cov khoom muaj nyob rau lwm qhov. Kub thiab o tuaj yeem hloov qhov tshwm sim. Txuag daim ntawv qhia pom zoo nrog cov ntaub ntawv qib, xim, lub taub hau kub, txhaj tshuaj thiab pwm version.
Covparison programming qhiamuab ib tug step-by-step tuning txoj kev. Rau qhov project no, FAT yuav tsum sib piv cov ntaub ntawv khaws tseg zaum kawg nrog rau daim ntawv qhia phab ntsa ntsuas thiab qhov hnyav ib feem.
Khiav lub Hoobkas sim uas teb qhov kev txiav txim yuav khoom
Kev kuaj pom zoo ntawm lub Hoobkas tsis yog kev ua qauv qhia tshuab. Nws yog kev tswj xyuas kom ua cov khoom pom zoo raws li cov ntaub ntawv teev tseg. Cov txiaj ntsig yuav tsum qhia tias qhov twg tau sim, nws tau ntsuas li cas thiab qhov twg tseem nyob sab nraud ntawm qhov ntsuas.
EUROMAP 46.2 muaj txiaj ntsig kev ntsuas ntsuas. Nws hu rau lub tshuab kom muaj kev ruaj ntseg, cov khoom zoo kom tau raws li cov neeg siv khoom xav tau, thiab cov ntaub ntawv txheej txheem tseem ceeb yuav tsum tau sau tseg. Kinggle cov txheej txheem muag khoom kuj hais tias cov neeg siv khoom tuaj yeem raug caw tuaj koom qhov kev xeem. Tig lub cib fim ntawd mus rau hauv cov txheej txheem sau ua ntej qhov kev sim pib.
- Cia cov ntawv xeem.Txheeb xyuas qhov kev hloov kho, pwm, kho lub taub hau, kab noj hniav los yog qhov hluav taws xob suav, thiab txhua qhov kev xaiv.
- Sau cov formulation.Sau cov qib resin, tus neeg muag khoom, xim pob, additives thiab regrind txoj cai. Khaws cov khoom txaus los ntawm ib qho kev paub ntau yog tias ua tau.
- Txheeb xyuas qhov teeb tsa.Sau lub thoob thiab lub taub hau kub, qhov chaw txhaj tshuaj, cov ntaub ntawv profile, lub tshuab tshuab, cov dej txias-dej thiab cov xwm txheej automation.
- Mus txog kev ua haujlwm ruaj khov.Tsis txhob xaiv thawj qhov uas tau txais. Pom zoo rau cov cai tswj kev ruaj khov thiab cov qauv qhov rai ua ntej ntsuas kev ua tau zoo.
- Ntsuas qhov sib npaug loj.Ntsuas qhov ua tiav, nyem thiab lwm yam luas. Paub meej tias tag nrho cov pawg parison tawm tsam qhov kev hais tawm accumulator.
- Tshawb xyuas cov khoom zoo.Siv cov chaw pom zoo thiab cov txheej txheem rau phab ntsa thickness, qhov ntev, qhov hnyav, kev ua haujlwm tsis zoo thiab pom qhov tsis xws luag.
- Suav txais cov zis.Qhia tag nrho cov voj voog, tag nrho qhov chaw, tsis lees paub thiab nres nyob rau lub sijhawm pom zoo. Khaws lub voj voog qhuav raws li cov ntaub ntawv cais.
- Ntsuas cov khoom siv hluav taws xob.Cov ntaub ntawv voltage, lub zog, compressed-cua siab thiab ntws, txias-dej kub, siab thiab ntws ntawm cov ciam teb.
- Sib tw repeatability.Txheeb xyuas qhov loj me, parison txoj hauj lwm thiab cov khoom ntsuas thoob plaws lub qhov rais qauv, tsis yog ntawm ib qho uas tau xaiv.
- Kaw deviations.Muab txhua yam khoom ua tsis tiav rau tus tswv, kev nqis tes ua, cov ntaub ntawv pov thawj thiab hnub kawg ua ntej kev pom zoo xa tuaj.
Khaws cov ntawv nyoos nrog cov ntawv sau sau tseg. Cov duab yuav tsum qhia cov qauv qhia thiab ntsuas qhov chaw. Daim ntawv qhia cov ntaub ntawv, ceeb toom thiab cov ntawv sib txawv yog ib feem ntawm cov pov thawj. Covtshuab moulding tshuab FAT qhiamuaj lub moj khaum kev lees txais puv.
Cov qauv xaiv kuj xav tau txoj cai. Cov lej hauv ib ntus thiab tsis txhob hloov cov qauv ua tsis tiav nrog qhov zoo dua. Yog tias qhov chaw hloov pauv, pib ib pawg qauv tshiab thiab sau lub sijhawm hloov pauv. Qhov no ua rau qhov tshwm sim traceable. Nws kuj cais qhov kev hloov pauv ib txwm los ntawm kev txiav txim siab txoj kev txhim kho.
Ua ntej kev pom zoo ua zaub mov xa tuaj, sib piv cov ntaub ntawv xeem nrog rau daim ntawv kos npe yuav tsum tau ua matrix. Kev kuaj xyuas lub tshuab ua haujlwm tsis tuaj yeem kaw qhov qhib cov khoom zoo. Ib qho kev xeem uas tsis tuaj yeem ua tiav yuav tsum nyob twj ywm pom nrog lub laj thawj thiab pom zoo raws li txoj hauv kev.
Npaj ib qho RFQ uas lub tshuab tsim tuaj yeem tsim ua haujlwm
Qhov kev thov tsis meej rau "ib lub tshuab 120 liter tshuab moulding" caw cov lus pom tsis meej. Xa ib pob khoom siv compact hloov. Nws tsis tas yuav ua kom zoo tag nrho, tab sis nws yuav tsum cais cov kev cai paub los ntawm kev txiav txim siab qhib.
Pib nrog cov khoom kos duab kos duab lossis 3D cov ntaub ntawv. Ntxiv cov duab thaum lawv piav txog caj dab, ntxig, tuav lossis luas. Qhia lub hom phiaj ua tiav qhov hnyav thiab txheeb xyuas cov phab ntsa tseem ceeb. Sau npe cov ntaub ntawv qib thiab ib qho kev tso cai regrind. Yog tias muaj tshuaj lom neeg los yog kev ntsuas kev tswj hwm teeb meem, hais cov qauv thiab cov khoom siv.
Ces txhais ntau lawm. Muab qhov chaw lees txais ib teev lossis ib hnub, muaj kev hloov pauv, npaj automation thiab cov kauj ruam hauv qab. Qhia seb qhov project puas muaj pwm tshiab. Yog tias muaj pwm twb muaj lawm, muab nws cov duab sib dhos, qhov hnyav, tuab, mounting thiab kev pabcuam kev sib txuas.
Cov ntaub ntawv chaw yuav tsum muaj xws li hluav taws xob, zaus, compressed-air muaj peev xwm, txias-dej tej yam kev mob, ntshiab qhov siab, nkag qhov rooj, crane thiab pem teb cov ntaub ntawv. Tsis txhob tos kom txog thaum kev teeb tsa los sib piv cov khoom no nrog lub tshuab. Cov dej num loj tuaj yeem raug txwv los ntawm rigging thiab cov khoom tuav tau yooj yim raws li extrusion.
Txuas nrog kev nug
Cov khoom lag luam thiab pwm kos duab, cob qhia cov ntsiab lus, cov hom phiaj tsim tawm, cov qauv zoo, cov khoom siv hluav taws xob, kev txwv kev txwv thiab qhov xav tau automation Scope.
Thov nyob rau hauv lub tswv yim
Kev xaiv lub taub hau zaum kawg, ntsia hlau thiab tsav, pwm haum daim ntawv qhia, thaj tsam siv hluav taws xob, kev teeb tsa, kev lees paub raws tu qauv, cov kev xaiv thiab kev tsis suav nrog.
Nug kom tiav qhov yuav tsum tau ua matrix. Txhua kab yuav tsum hais tias "ua raws," "yuav tsum tau hloov," lossis "tsis suav nrog," ua raws li cov lus qhia. Qhov no yooj yim dua rau kev tshuaj xyuas dua li cov nqe lus tawg hauv email. Kinggle muab ibchaw downloadrau cov ntaub ntawv technical thiab adaim ntawv nug txog qhov projectrau kev sib cuag thawj zaug.
Thaum KGB100B koom nrog hauv cov npe luv
KGB100B tsim nyog tau txais kev tshuaj xyuas zoo dua thaum cov khoom poob ze ntawm nws cov ntawv thov loj thiab cov kev kuaj xyuas engineering zoo sib xws. Cov nplooj ntawv khoom npe npe tshuaj chim chim, nws pib qhov chaw, tsheb teeb meem, floats, cov khoom ua si thiab rooj tog raws li daim ntaub ntawv. Daim ntawv teev npe no qhia txog cov phiaj xwm phiaj xwm, tab sis nws tsis yog pov thawj tias ib feem yuav khiav.
Cov ntaub ntawv luv luv muaj zog muaj plaub yam. Cov pwm haum nrog chav rau kev txav mus los thiab kev pabcuam. Gross parison mass fits qhov kev xaiv lub taub hau. Extrusion rov qab txhawb nqa lub voj voog xav tau nrog cov khoom siv. Lub Hoobkas tuaj yeem muab cov khoom siv hluav taws xob thiab kev tuav pov hwm ntawm thaj tsam tau pom zoo.
Txav mus rau lwm qhov kev teeb tsa thaum ib qho ntawm cov xwm txheej tsis ua tiav. Lub accumulator loj tuaj yeem daws qhov phom loj tab sis tsis yog pwm dav. Lub platen loj dua tuaj yeem daws lub hnab ntawv pwm tab sis tsis rov ua dua. Ib lub tshuab loj sib txawv yuav muaj kev lag luam ntau dua thaum cov khoom me me dua li lub platform ua haujlwm ntau.
Kuj ncua thaum cov ntaub ntawv tsis tiav. Lub vev xaib lub taub hau ntawm lub taub hau thiab cov cua tsis sib haum yuav tsum tau sau cov lus qhia meej. Tus naj npawb ntawm lub voj voog qhuav tsis tuaj yeem kaw qhov tso zis lav. Cov no yog cov khoom ib txwm muaj rau kev cog lus technical, tsis yog vim li cas los twv.
Qhov kev txiav txim siab yuav yuav tsum xaus nrog ib feem ntawm txoj kev sim. Yog tias lub tshuab tuaj yeem ua kom ruaj khov, siv tau qhov chaw ntawm qhov kev pom zoo thiab kev siv hluav taws xob ciam teb, tus qauv haum rau txoj haujlwm. Yog tias cov pov thawj ntawd ploj lawm, daim ntawv teev npe tseem nyob ib ntus.
Cov lus nug uas nquag nug
Cov khoom dab tsi tuaj yeem KGB100B 120L tshuab moulding ua?
Kinggle teev cov khoom siv hluav taws xob, qhov chaw pib, kev thaiv tsheb, ntab, khoom ua si thiab rooj tog zaum ntawm nplooj ntawv KGB100B. Cov no yog daim ntawv thov siv, tsis yog kev pom zoo tsis siv neeg. Cov khoom tiag tiag tseem xav tau kev kuaj xyuas pwm loj, tag nrho parison loj, clamp thov, khoom siv, tshem tawm txoj kev thiab cua txias.
Puas yog 120 L txhais tau tias txhua lub thawv hauv qab 120 L yuav haum?
Tsis yog. Nominal ntim ntim tsuas yog ib qho kev soj ntsuam tus nqi xwb. Ib feem hauv qab 120 L tseem tuaj yeem tshaj lub hnab ntawv pwm, qhov kev txwv-thaj chaw txwv, accumulator xav tau lossis muaj qhov chaw tshem tawm. Xa cov khoom thiab pwm kos duab rau kev tshuaj xyuas cov qauv tshwj xeeb.
KGB100B puas tuaj yeem ua 15 kg tiav HDPE khoom?
Tsis txhob ua qhov kev xav ntawd los ntawm lub rooj rau pej xeem. Nplooj ntawv luam tawm 9(15) kg raws li PE accumulator-yuav siv tau, pom tau tias nrog ob lub taub hau muaj peev xwm. Gross parison mass muaj xws li ib feem thiab tag nrho cov flash los yog trim. Lub taub hau xaiv, resin thiab cov txheej txheem siv tau yuav tsum tau lees paub los ntawm Kinggle thiab ua pov thawj hauv kev sim.
Puas yog 320 pcs / h cov khoom tsim tawm?
Tsis yog Kinggle cov ntawv lo 320 pcs / h raws li lub voj voog qhuav. Cov txiaj ntsig tau txais muaj xws li extrusion, parison tsim, tshuab, txias, tshem tawm, trimming, tsis lees paub thiab nres. Qhia qhov yuav tsum tau txais cov zis thiab xyuas nws nrog cov pwm tsim thiab cov khoom siv.
Yuav siv zog npaum li cas los sib piv?
Sib piv cov khoom lag luam ntsig txog lub zog nyob rau hauv tib lub pwm, cov khoom lag luam, resin, cov kev cai zoo thiab kev xeem ciam teb. KGB100B nplooj ntawv luam tawm 52 txog 60 kW raws li qhov nruab nrab lub zog kab, uas yog siv hluav taws xob siv. Ntsuas kWh / kg thiab kWh ib feem tau txais thaum lub sij hawm ruaj khov ntau lawm es tsis txhob hloov cov nplooj ntawv tus nqi.
Kuv yuav tsum xa cov ntaub ntawv dab tsi rau KGB100B hais?
Xa cov duab kos duab thiab duab, qhov ntev, qhov hnyav tiav, cov khoom siv phab ntsa, cov khoom siv qib, regrind txoj cai, tau txais cov khoom tsim tawm, kev ntsuam xyuas zoo, cov ntaub ntawv pwm, cov khoom siv hluav taws xob thiab cov kev xav tau automation. Kos cov khoom tsis paub meej. Qhov no muab cov ntaub ntawv txaus rau tus neeg muag khoom kom paub meej tias lub taub hau, pwm haum thiab kev sim ntsuas.
