Configure KGB110A los ntawm cov khoom ntsuas ntsuas, tsis yog los ntawm 160L lub npe ib leeg. Sau qhov geometry, net hnyav, daim ntawv qhia phab ntsa, cob, luas thiab ntau lawm lub hom phiaj. Tom qab ntawd siv cov khoom siv los kuaj xyuas lub hnab ntawv pwm, qhov kev thov tag nrho parison, extrusion rov qab, clamp yuav tsum tau thiab cov khoom siv hauv tsev.
Lub 160 liter tshuab moulding tshuab tuaj yeem ua cov khoom sib txawv. Ib txoj kev hollow barrier muaj ib tug dav projected cheeb tsam. Lub pontoon yuav muaj qhov ntev kos cov cheeb tsam thiab cov kev cai sib khi. Lub rooj vaj huam sib luag tuaj yeem dav tab sis kuj ntiav. Ib lub npe qauv tsis tshem tawm cov kev sib txawv.
Qhov zoo tshaj plaws pib taw tes yog feem ntau cov khoom twb nyob rau hauv lub buyer lub rooj. Ntsuas nws, ntsuas nws thiab kos cov cheeb tsam uas tseem ceeb. Cov qauv ntawd dhau los ua qhov sib txuas ntawm cov khoom tsim, kev siv, kev teeb tsa lub tshuab thiab kev lees paub.
Cov ntaub ntawv rau nplooj ntawv uas yuav tsum tau tsav qhov project
Dimensioned ib feem kos duab, tag nrho loj, qhib, ntxig thiab sib dhos interfaces.
Net qhov hnyav, qib khoom, xim, additives thiab tso cai regrind.
Phab ntsa-thickness daim ntawv qhia nrog rau qhov chaw tseem ceeb thiab cov khoom yuav tsum tau kuaj.
Trim daim ntawv qhia uas qhia sab saum toj flash, hauv qab tus Tsov tus tw, tuav seem thiab lwm yam poob.
Txais lub hom phiaj tso zis, hloov qauv, automation thiab kev ua haujlwm qis.
Lub Hoobkas fais fab, cua, dej, nkag, nqa thiab muaj qhov chaw ntawm tes.
Cov ntaub ntawv luam tawm:Kinggle cov nplooj ntawv tam sim no thiab cov ntawv thov tso KGB110A hauv chav 160L. Tib nplooj ntawv tam sim no qhia txog 120 L hauv cov ntsiab lus thiab lub peev xwm siab tshaj plaws. Kab lus no ua raws li kev tshaj tawm 160L cov khoom muag, tab sis qhov tseeb txiav txim siab yuav tsum tau lees paub hauv cov lus hais thiab kev pom zoo.
Pib nrog cov qauv khoom, tsis yog daim ntawv teev npe
Cov qauv qhia koj qhov twg qhov kev txiav txim siab tshuab tuaj yeem ua tsis tiav. Nws qhov ntev sab nrauv cuam tshuam rau pwm. Nws qhov hnyav thiab trim cuam tshuam rau lub accumulator. Nws qhov dav dav cuam tshuam rau thaj chaw uas tau npaj tseg. Cov kab sib sib zog nqus thiab cov tes tuav cuam tshuam rau phab ntsa faib. Cov cwj pwm ua kom txias muaj feem cuam tshuam rau lub sijhawm voj voog thiab tshem tawm.
Lub ntim tseem siv tau. Nws pab tso qhov project nyob rau hauv ib tug dav siv tshuab ntau yam. Tsis tau ob yam khoom uas muaj tib lub ntim ntim yuav xav tau lub taub hau sib txawv, clamps lossis pwm qhib. A bulky float can contain more air while using less resin than a dense technical panel with local ribs and thick mounting zones.
Tsis txhob cia siab rau tus neeg sib tw ua tiav ib feem uas yog tib qhov chaw. Yog tias ua tau, ntxiv cov ntaub ntawv tsim thawj thiab qhov xav tau kev ua tau zoo. Ib qho qauv luam tawm tuaj yeem suav nrog phab ntsa tuab uas them nyiaj rau cov pwm qub lossis txheej txheem. Rov ua phab ntsa ntawd yam tsis nkag siab nws txoj haujlwm tuaj yeem ntxiv qhov hnyav yam tsis tau txhim kho kev ua haujlwm.
Kinggle cov ntaub ntawvkev muag khoompib nrog cov duab khoom, kos duab, qhov hnyav, qhov loj thiab cov khoom siv. Nws kuj nug txog cov thickness, cov zis thiab cov tshuaj tiv thaiv kev tiv thaiv. Qhov kev txiav txim ntawd yog qhov siv tau vim tias lub tshuab pom zoo ua raws li cov khoom pov thawj.
Cov qauv ntaub ntawv yuav tsum muaj ib tus lej hloov kho. Yog lub caj dab, tuav, ntxig lossis tag nrho ntev hloov, hloov cov ntaub ntawv ua ntej lub tshuab thiab pwm yog khov. Qhov no zam ib qhov project uas cov lus hais haum rau cov qauv thaum ntxov tab sis cov duab kos tsis haum rau lub xov tooj ntawm tes.
Tsim ib tus qauv dossier uas tuaj yeem muaj sia nyob kev tshuaj xyuas engineering
Pib nrog kev ntsuas yooj yim. Sau tag nrho ntev, dav thiab qhov siab. Ntxiv qhov qhib diameters, caj dab tiav, flange loj, tuav clearance thiab txoj hauj lwm ntawm txhua qhov ntxig. Kos cov kab sib faib thiab pom thaj chaw pinch yog tias tus qauv nthuav tawm lawv.
Ntsuas cov khoom tiav ntawm qhov ntsuas ntsuas. Tom qab ntawd cais cov khoom tshem tawm uas tsis yog tshuab moulded. Lub hau, ntsaws, hlau ntxig lossis ua npuas dej yuav tsum tsis txhob suav tias yog cov yas molded. Sau cov ntaub ntawv txheeb xyuas cov txheej txheem es tsis txhob xav tias cov polymer los ntawm qhov tsos.
Phab ntsa thickness xav tau daim ntawv qhia chaw. Sau cov ntsiab lus ntawm daim duab lossis duab. Xws li cov ces kaum, lub xub pwg hloov pauv, tuav, lub hauv paus tiv tauj, mounting zones thiab broad panels. Ib qho nruab nrab tuab tuab npog qhov nyias qhov chaw uas yuav tswj tau qhov kev ua tau zoo.
Tom ntej no, sau cov khoom kuaj. Ib qho ntab, thaiv kev tsheb, rooj tog vaj huam sib luag thiab cov thawv ntim khoom tsis muaj cov txheej txheem dhau los. Siv tus neeg yuav khoom qhov kos duab tiag tiag, kev cai tswj hwm lossis kev sim sab hauv. Tsis txhob qiv qhov siab poob, thauj khoom lossis xau kuaj los ntawm cov khoom tsis sib xws.
| Cov ntaub ntawv pov thawj | Yuav sau li cas | Kev txiav txim siab tshuab cuam tshuam |
|---|---|---|
| Zuag qhia tag nrho geometry | Dimensioned kos duab lossis kos cov ntaub ntawv 3D | Pwm lub hnab ntawv, centerline, lub taub hau txoj hauj lwm thiab txoj kev tshem tawm |
| Net molded hnyav | Nyhav yam tsis muaj kev sib sau ua ke | Pib taw tes rau tag nrho parison pawg |
| Phab ntsa faib | Tus lej qhov chaw nrog txoj kev ntsuas xaiv | Parison profile, txhaj tshuaj tua kab thiab cov txheej txheem sim |
| Resin system | Qib, tsum, xim, additives thiab regrind txoj cai | Screw haum, yaj tus nqi thiab ua qhov rais |
| Trim thiab nyem | Cia siab rau sab saum toj, hauv qab, kov thiab sab seem | Accumulator xav tau thiab regrind load |
| Kev xeem ua haujlwm | Lub npe txoj kev, mob, qauv loj thiab hla txwv | Pwm tsim, cua txias, phab ntsa phiaj thiab FAT Scope |
| Txais cov zis | Cov khoom zoo hauv ib teev lossis ua haujlwm tom qab kuaj xyuas | Rov qab tus nqi, txias, automation thiab downstream peev |
Ib qho piv txwv yog pov thawj, tsis yog tag nrho cov specification. Nws yuav muaj hnub nyoog, warped los yog absorbed tshuaj. Siv nws los nug cov lus nug zoo dua, tom qab ntawd tso cov duab pom zoo thiab cov qauv ntsuas saum toj no cov qauv ntawm lub cev hauv cov ntaub ntawv hierarchy.
Nyeem KGB110A specification raws li ib txheej ntawm cov tshev
CovKGB110A khoom nploojluam tawm 6.6 x 4.2 x 5.2 m tshuab loj thiab 22 t tshuab hnyav. Nws seem clamping teev 760 kN, 1100 x 1400 mm platen thiab 1000 x 1400 mm siab tshaj pwm. Cov nplooj ntawv tseem muab 610 txog 750 mm pwm-thickness ntau yam.
Rau kev qhib thiab txav, nplooj ntawv qhia 600 txog 1600 mm thiab 600 mm txav stroke. Cov lej no xav tau cov pwm sib dhos ntawm ib sab ntawm lawv. Cov lus nug tseem ceeb yog seb qhov ua tiav qhov txias tuaj yeem tso tawm thiab tawm hauv pwm nrog cov neeg hlau npaj, ntxig thiab luas tseem txuas nrog.
Cov seem extrusion teev cov ntsia hlau 110 hli, 25 L / D piv, 75 kW extruder lub cev muaj zog thiab plaub thaj chaw cua sov. Tshaj tawm HDPE melting muaj peev xwm yog 160 txog 200 kg / h. Qhov ntau yog nyob rau nplooj ntawv HDPE lo lus. Nws tsis ua pov thawj tib tus nqi rau lwm yam khoom lossis kev tsim.
Lub taub hau ntu tshaj tawm 12 (20) L accumulator muaj peev xwm thiab 9 (15) kg PE accumulator hnyav. Nws kuj teev txog 450 (600) mm siab kawg tuag-pin txoj kab uas hla. Parenthetical qhov tseem ceeb tuaj yeem cuam tshuam txog kev xaiv kev teeb tsa, tab sis nplooj ntawv tsis txhais txoj cai. Lub tswv yim yuav tsum hais lub taub hau xaiv, tuag tooling thiab resin hauv paus.
Nplooj ntawv piav qhia tus qauv qauv nrog MOOG 100 thickness controller, neeg hlau caj npab thiab hauv qab tshuab tshuab. Cov no yog thawj-tog cov lus tshaj tawm. Cov lus hais tseem yuav tsum muaj npe txhua yam khoom siv, nws qhov interface thiab txhua qhov kev hloov pauv tshwj xeeb.
Lub Hoobkas nyeem:tsis txhob theej lub rooj rau hauv kev yuav khoom yam tsis muaj nws cov lus nug. Muab cov qauv ntsuas, kos duab pwm lossis kev siv hluav taws xob suav nrog ib sab ntawm txhua qhov kev qhia tshwj xeeb uas nws xav kom txaus siab.
Txhais cov khoom zoo rau hauv pwm haum thiab tshem tawm qhov chaw
Cov khoom siv kos duab ua pwm tsuas yog tom qab ntxiv cov tswv yim shrinkage, kab noj hniav hlau, cua txias, pinch-off, vents, caj dab tooling thiab mounting. Lub resulting sib dhos tuaj yeem loj dua li cov khoom. Ib feem uas zoo nkaus li xis nyob hauv qhov txwv 1000 x 1400 mm yuav dhau los ua nruj thaum sib txuas thiab txav khoom siv ntxiv.
Txheeb xyuas qhov dav, qhov siab thiab nruab thickness nyias nyias. Siv cov kev sib dhos ua tiav, suav nrog cov ntawv thaub qab thiab cov khoom siv. Paub meej tias tus qauv mounting tiv thaiv 1100 x 1400 mm platen siv. Qhia dej, hydraulic, pneumatic thiab hluav taws xob sib txuas hauv lawv qhov chaw nruab.
Qhov chaw qhib yog qhov teeb meem ntawm kev txav. Lub rooj vaj huam sib luag yuav xav tau kom tshem tawm cov kab sib sib zog nqus. Ib qho barrier tuaj yeem tawm hauv kab noj hniav ntawm lub kaum sab xis. Lub pontoon tuaj yeem hloov pauv tau thaum kub thiab yuav xav tau kev txhawb nqa thaum nqa tawm. Cov neeg hlau tuav thiab ib feem kev sib hloov xav tau lawv lub hnab ntawv swept.
Npaj cov pwm-hloov txoj hauv kev tib lub sijhawm. Nplooj ntawv KGB110A muab 22 t tshuab hnyav tab sis tsis luam tawm cov pwm qhov hnyav. Nug Kinggle rau qhov kawg pwm-qhov hnyav txwv, nqa cov ntsiab lus thiab kev teeb duab dav dav. Tom qab ntawd txheeb xyuas cov nroj tsuag crane, nuv qhov siab thiab mus kom ze.
Pwm txias tuaj yeem tswj tau tag nrho lub voj voog. Cov chaw loj xav tau kev sib npaug sib npaug, thaum cov yam ntxwv tuab yuav xav tau kom txias. Covextrusion tshuab moulding pwm qhianpog pinch-off, venting thiab Circuit Court npaj kom ntxaws ntxiv.
Xam tag nrho cov parison xav tau ua ntej xaiv lub taub hau
Lub accumulator yuav tsum xa tag nrho cov khoom uas tawm hauv qhov tuag thaum ib qho kev tshwm sim molding. Cov khoom tiav qhov hnyav tsuas yog ib feem. Lub taub hau kuj pub flash, tails, lis seem thiab txhua yam khoom uas cov txheej txheem trimming tshem tawm.
Gross parison mass = net molded product + flash thiab trim + documented process allowance
Siv cov ntsuas los yog pwm-derived tus nqi. Tsis muaj universal seem feem pua ntawm floats, barriers, rooj tog thiab technical parts.
Kinggle luam tawm 9 (15) kg raws li PE accumulator-hnyav kab rau KGB110A. Kho nws raws li lub taub hau thiab cov ntaub ntawv siv, tsis tiav-cov khoom muaj peev xwm. PE qib, kub kub, cov ntsiab lus rov ua dua thiab qhov chaw tuag tuaj yeem hloov tus cwj pwm siv tau. Lwm cov resin xav tau nws tus kheej tshuaj xyuas.
Parison ntev tseem ceeb nrog huab hwm coj. Lub parison ntev tuaj yeem sag lossis ncab ua ntej pwm kaw. Kev tuag dav tuaj yeem txo qis qhov xav tau nyob ib puag ncig cov khoom tab sis tuaj yeem hloov lub taub hau thiab cov cuab yeej siv. Sau qhov loj me, qhov sib txawv programmed, lub sij hawm extrusion thiab parison txoj hauj lwm thaum lub sij hawm mus sib hais.
Kev thov tag nrho tseem cuam tshuam rau kev rov ua dua. Hnyav flash yuav haum lub accumulator thaum tsim ib tug loj seem kwj. Lub granulator, conveying thiab blending system yuav tsum ua kom. Yog hais tias regrind rov qab mus rau cov khoom, nws cov feem pua thiab kev tswj kev sib kis yog nyob rau hauv daim ntawv pom zoo.
Tawm tswj ntau yam rau kev kho qhov profile. Lub taub hau khiav ntawm nws cov tswv yim ntug yuav muaj chav me me rau cov fab tuab dua lossis ntev dua parison. Qhov kev sim yuav tsum qhia qhov loj tag nrho ruaj khov, siv tau lub cushion thiab rov ua dua parison tso rau ntawm lub qhov rais piv txwv.
Tig daim ntawv qhia phab ntsa mus rau hauv kev tswj hwm parison profile
Daim ntawv qhia phab ntsa hais tias qhov twg cov khoom xav tau cov khoom siv. Lub parison profile hais tias thaum tuag qhov sib txawv yuav tsum hloov raws li lub parison tawm lub taub hau. Txuas ob cov ntaub ntawv no muaj txiaj ntsig ntau dua li kev luam ib qhov profile los ntawm lwm qhov.
Sau cov phab ntsa qhov chaw ntawm daim duab kos duab. Tom qab txhua qhov kev sim, txiav los yog ntsuas tib qhov chaw hauv tib qho kev txiav txim. Sau ib feem hnyav thiab kho qhov profile nrog txhua pab pawg. Yog tias ntau qhov chaw hloov pauv ib zaug, pab pawg poob qhov laj thawj ntawm qhov tshwm sim.
Nplooj ntawv KGB110A npe MOOG 100 thickness controller. AMoog DigiPack III phau ntawv tuav los ntawm Kingglepiav qhia txog tus txheej txheem tswj hwm uas khaws cov ntaub ntawv cov khoom thiab cuam tshuam cov txheej txheem phab ntsa tuab rau lub tshuab ua haujlwm. Nws yog cov ntaub ntawv pov thawj muaj txiaj ntsig, tab sis nws tsis txheeb xyuas qhov tseeb ntawm tus maub los cuam tshuam rau txhua KGB110A.
Ib qhov profile tsis tuaj yeem kho txhua qhov tsis xws luag. Qhov tuag thiab mandrel geometry, lub taub hau centering, yaj kub, parison swell thiab pwm sij hawm tseem tseem ceeb. Yog tias lub parison nkag mus rau hauv pwm tawm ntawm qhov chaw, ntxiv cov khoom yuav zais cov tsos mob thaum nce qhov hnyav.
Thaum ib feem dhau mus, txuag daim ntawv qhia ua tiav. Xws li cov khoom siv, xim, qhov kub thiab txias, qhov chaw txhaj tshuaj, cov ntaub ntawv profile, tshuab, cua txias thiab kho pwm. Covparison programming qhiamuab ib tug fuller tuning sequence.
Match extrusion rov ua kom txias thiab txais cov zis
Lub rooj rau pej xeem sau npe 160 txog 200 kg / h raws li KGB110A HDPE melting-capacity range. Cov lus nug ntau lawm yog seb cov ntsia hlau xaiv tuaj yeem rov qab cov khoom siv ua ntej txhaj tshuaj tom ntej thaum tswj kev ruaj khov zoo. Ib daim ntawv qhia siab tshaj plaws tsis tuaj yeem teb qhov ntawd los ntawm nws tus kheej.
Xam tag nrho cov kev thov ib teev los ntawm kev ua tiav parison. Siv cov kev npaj molding txheej xwm ib teev twg thiab active outlets. Tom qab ntawd sib piv cov txiaj ntsig nrog qhov ntsuas qhov ntsuas rau qhov tseeb resin, xim thiab rov ua dua.
Tag nrho cov khoom xav tau, kg / h = tag nrho parison pawg x molding txheej xwm ib teev x active parisons ib qhov kev tshwm sim
Nplooj ntawv KGB110A sau 320 pcs / h, tab sis sau nws lub voj voog qhuav. Lub voj voog qhuav yog siv tshuab-tsim. Cov khoom tso tawm muaj xws li accumulator rov qab, parison tsim, tshuab, cua txias, tso pa, qhib, tshem tawm, trimming thiab zoo poob.
Qhov loj feem ntau siv ntau lub voj voog txias. Lub sij hawm ntawd tuaj yeem tso cai rau lub extruder rov qab lub taub hau. Yog tias zoo pwm txias ua kom lub voj voog luv, qhov yuav tsum tau yaj tus nqi nce. Cycle optimization yuav tsum yog li ntawd xyuas qhov rov qab thiab phab ntsa zoo, tsis yog pwm kub xwb.
Tshaj tawm qhov lees txais ib teev tom qab tau txais kev pom zoo. Khaws lub voj voog qhuav, tag nrho cov voj voog, tsis lees paub thiab nres hauv cov kab sib cais. Covcycle-time optimization phau ntawv qhiaqhia tau hais tias yuav ua li cas los tsim ib lub sijhawm los ntawm theem nyiaj txiag.
Tshawb xyuas 760 kN tiv thaiv thaj tsam thiab cov txheej txheem siab
Kinggle tshaj tawm 760 kN clamping quab yuam rau KGB110A. Tus lej ntawd yuav pab tau tsuas yog nyob ib sab ntawm kab noj hniav qhov chaw npaj thiab qhov pom zoo sab hauv siab. Qhov projected cheeb tsam yog kab noj hniav silhouette ntawm lub dav hlau parting. Nws tsis yog ntim ntim lossis thaj chaw.
Ib qho kev thaiv dav lossis cov rooj zaum tuaj yeem tsim kev sib cais tseem ceeb txawm tias nws ntiav. Ib qhov tob tab sis nqaim ntab yuav coj txawv txawv. Multi-cavity los yog ntau qhov layouts nce tag nrho qhov projected cheeb tsam pom los ntawm lub clamp.
Cov nplooj ntawv khoom sau npe 0.8 MPa tshuab siab. Siv lub qhov rais tsim tawm tiag tiag hauv kev suav. Pwm venting, yaj kub, nto nthuav dav thiab phab ntsa tuab tuaj yeem hloov qhov xav tau siab. Lub Hoobkas kuaj yuav tsum sau cov txheej txheem siab thiab muaj lub tshuab-inlet siab.
Flash mob yog cov pov thawj muaj txiaj ntsig. Kev loj hlob flash tuaj yeem taw tes rau kev sib cais ntau dhau, hnav thaj chaw pinch, teeb meem kev sib dhos lossis cov khoom siv ntau dhau. Tsis txhob kho txhua qhov teeb meem flash los ntawm kev ua kom muaj zog clamp. Tshawb xyuas cov pwm thiab txheej txheem ua ke.
Lub tshuab xa khoom thiab cov khoom lag luam pwm yuav tsum pom zoo ib qho kev suav. Muab qhov projected cheeb tsam, txheej txheem siab, clamp yuav tsum tau thiab cov assumed yam nyob rau hauv cov ntaub ntawv technical. Qhov no tiv thaiv ob qhov kev pom zoo sib cais uas tso siab rau cov kev xav sib txawv.
Txheeb xyuas qhov kev suav dua yog tias kab noj hniav hloov pauv. Ntxiv ib feem thib ob, txav txoj kab sib faib los yog ua kom lub vaj huam sib luag loj tuaj yeem hloov qhov projected. Ntxig thiab sab ua yeeb yam kuj tseem tuaj yeem hloov pauv li cas pwm reacts. Daim duab puab kawg, es tsis yog ib qho khoom kos duab thaum ntxov, yuav tsum kaw daim tshev no.
Txhais cov ntaub ntawv txheej es tsis txhob cia siab rau cov kab lus tshwj xeeb
KGB110A nplooj ntawv hais tias lub platform tuaj yeem muab cov khoom lag luam ib txheej thiab tuaj yeem tsim cov txheej txheem ob txheej lossis ntau txheej. Tib lub rooj qhia tshwj xeeb rau pej xeem sau ib lub 110 hli ntsia hlau thiab ib lub 75 kW extruder lub cev muaj zog. Ib txoj haujlwm ntau txheej yog li xav tau kev teeb tsa kev teeb tsa tshaj li lub rooj txheej txheem.
Pib nrog cov khoom vim li cas rau lwm txheej. Tej zaum nws yuav yog xim tso rau hauv, siv cov khoom tseem ceeb los yog kev ua haujlwm tsis zoo. Qhia cov khoom nyob rau hauv txhua txheej thiab lub hom phiaj piv. Tshawb xyuas kev sib raug zoo, kev ua haujlwm kub thiab qhov tso cai hloov pauv.
Tom qab ntawd thov daim duab yaj kiab. Nws yuav tsum txheeb xyuas txhua tus extruder, adapter, lub taub hau channel thiab tswj taw tes. Cov lus pom zoo yuav tsum tau qhia qhov loj me ntawm lub cev muaj zog, cov khoom siv cua sov, kev tuav cov khoom siv thiab cov khoom siv kho dua tshiab. Daim ntawv lo "multi-layer" tsis txhais cov khoom siv no.
Kev hloov pauv kev ua haujlwm loj hlob nrog txhua txoj hauv kev. Purge ntim, ntxuav nkag, xim sib lawv liag thiab seem cais cuam tshuam rau lub sijhawm ua haujlwm. Yog tias cov khoom tsis xav tau ntau txheej txheej, cov txheej txheem ntxiv tuaj yeem ntxiv kev ua haujlwm yam tsis tsim tus nqi yuav khoom.
Ib txheej txheej kev taw qhia
Siv ib qho kev cob qhia cov kwj deg thaum cov khoom ua tau zoo, cov xim thiab cov khoom siv rov ua dua tshiab tuaj yeem ua tau raws li cov qauv phab ntsa.
Kev taw qhia ntau txheej
Thov ib qhov project-specific co-extrusion configuration thaum txhua txheej muaj cov ntaub ntawv muaj nuj nqi thiab kev txais ntau yam.
Kinggle covmulti-layer co-extrusion qhiapiav qhia txog txheej txheej thiab cov lus nug uas muaj nyob hauv RFQ.
Npaj lub cell ua kom tiav nyob ib ncig ntawm 22 t tshuab
Lub tshuab luam tawm qhov ntev yog 6.6 x 4.2 x 5.2 m. Lub tshuab hnyav yog 22 t. Cov txiaj ntsig no pib cog layout. Lawv tsis suav nrog kev pabcuam tshem tawm, ntaiv, tuav pwm, khoom siv cob, compressor, cua txias, tshem tawm lossis ua tiav hauv qab.
Tshawb xyuas txoj kev ntsug ua ntej. Lub tsev xav tau qhov siab txaus rau lub tshuab, nkag mus rau platform thiab npaj nqa nqa. Kos txoj hauv kev rau lub taub hau tuag thiab extruder Cheebtsam yog tias kev saib xyuas yuav tsum tau muab tshem tawm. Paub meej tias lub peev xwm crane thiab nuv ncav cuag los ntawm qhov kawg daim duab.
KGB110A nplooj ntawv luam tawm 0.3 MPa thiab 120 L / min rau cov dej txias. Daim ntawv phiaj xwm tseem xav tau qhov kub thiab txias, rov qab txwv, dej zoo, pom thiab qhov ntsuas hluav taws xob. Tus naj npawb txaus uas tsis muaj qhov kub thiab txias tsis tuaj yeem ua rau qhov txias txias.
Rau compressed cua, nplooj ntawv teev 0.8 MPa thiab 1.8 m³ / min. Paub meej tias qhov siab tshaj plaws thiab qhov nruab nrab xav tau, txais qhov loj me, dew point, pom thiab qhov sib txuas loj. Cov txheej xwm tshuab loj tuaj yeem rub lub siab thaum lub taub hau qis dua.
Cov nplooj ntawv sau npe 52 txog 60 kW raws li kev siv hluav taws xob nruab nrab. Vim tias kW yog lub zog, kho qhov no raws li kev tshaj tawm kev ua haujlwm-hwj chim siv. Tsis txhob hloov mus rau kWh rau ib feem.EUROMAP 46.2ties cov khoom ntsig txog kev ntsuas lub zog rau lub tshuab muab, pwm thiab cov khoom lag luam nyob rau hauv cov xwm txheej ruaj khov.
CovFactory Utility Guidenpog thaj tsam hluav taws xob, huab cua, dej, kev ua haujlwm hauv pej xeem thiab kev nkag. Siv daim duab kos duab kos duab kawg es tsis yog lub hnab ntawv pej xeem rau kev pom zoo rau kev teeb tsa.
Ua pov thawj qhov kev teeb tsa nrog cov khoom siv traceable
Lub Hoobkas sim yuav tsum rov tsim cov khoom lag luam uas tau piav qhia hauv cov ntaub ntawv ua piv txwv. Cov pwm pom zoo, resin thiab cov kev xaiv loj yuav tsum muaj. Yog tias siv qhov hloov pauv, sau qhov sib txawv thiab txwv cov lus xaus raws li.
Npaj cov qauv ua ntu zus ua ntej khiav. Number qhov chaw nyob rau hauv molding kev txiav txim. Txhais thaum twg ruaj khov pib thiab ntev npaum li cas lub qhov rais ntsuas. EUROMAP 46.2 yuav tsum muaj lub tshuab ruaj khov rau nws cov khoom lag luam ntsig txog lub zog txoj kev thiab cov ntaub ntawv cov khoom zoo raws li ib feem ntawm cov ntsiab lus ntsuas.
- Txheeb xyuas qhov kev teeb tsa.Sau tshuab serial tooj, xaiv lub taub hau, tuag tooling, pwm kho, xws li thiab ntsia automation.
- Txheeb xyuas cov qauv.Sau qib resin, tus neeg muag khoom, xim, additives thiab regrind cov ntsiab lus los ntawm cov khoom siv tiag tiag.
- Khaws daim ntawv qhia.Txuag qhov kub thiab txias, qhov chaw txhaj tshuaj, phab ntsa profile, tshuab chaw, cua txias thiab automation sijhawm.
- Kaw qhov sib npaug loj.Ntsuas cov khoom, txhua qhov trim kwj thiab tag nrho txhaj tshuaj. Sib piv nws nrog lub hauv paus ntsiab lus.
- Ntsuas daim ntawv qhia phab ntsa.Siv tus lej ntawm qhov chaw thiab pom zoo txoj kev. Khaws cov ntawv nyeem txuas rau txhua tus lej qauv.
- Khiav cov kev kuaj xyuas ua haujlwm.Thov tsuas yog cov khoom tshwj xeeb cov kev xeem thiab cov kev txwv sau rau hauv qhov kev pom zoo yuav tsum tau ua.
- Suav tso zis ncaj ncees.Cais lub voj voog qhuav, tag nrho cov voj voog, txais qhov chaw, tsis lees paub thiab nres nyob rau lub sijhawm pom zoo.
- Sau cov khoom siv.Ntsuas lub zog, huab cua thiab dej ntawm cov ciam teb uas tau txiav txim siab thaum cov khoom siv tau txais.
- Kaw cov khoom qhib.Muab txhua qhov sib txawv rau tus tswv, kho kom raug, cov ntaub ntawv pov thawj thiab hnub kawg.
Tsis txhob xaiv qhov zoo tshaj plaws rau daim ntawv tshaj tawm. Khaws ib ntu uas qhia tias muaj kev hloov pauv. Yog tias daim ntawv qhia hloov pauv, pib ib pawg qauv tshiab. Qhov no cais cov txheej txheem kev txhim kho los ntawm kev lees paub pov thawj.
Pom zoo rau cov cuab yeej ntsuas ua ntej kev xeem. Cov ntaub ntawv teev cov kev daws teeb meem, cov txheej txheem tuab thiab cov txheej txheem calibration uas lawv cuam tshuam rau qhov tshwm sim. Siv cov cuab yeej tib yam rau cov qauv ua ntu zus. Yog tias tus neeg yuav khoom thiab tus neeg muag khoom ntsuas nrog ntau txoj kev, sib piv cov txheej txheem ua ntej txiav txim siab tias cov khoom tsis pom zoo.
Qhov tshwm sim ua tsis tiav xav tau cov ntsiab lus. Khaws cov chaw muaj feem xyuam, tswb keeb kwm, tus lej qauv thiab cov ntaub ntawv tshuaj xyuas. Ib qho kho kom raug tuaj yeem ua pov thawj qhov kho, tab sis nws yuav tsum tsis txhob tshem tawm qhov sib txawv ua ntej. Cov keeb kwm no pab pawg txiav txim siab seb qhov kho puas ruaj khov lossis ib ntus.
Khaws cov ntaub ntawv nyoos, duab, daim ntawv qhia xa tawm thiab kos npe cov ntsiab lus ua ke. CovHoobkas lees txais kev xeem ntawv qhiamuab cov txheej txheem dav dav rau kev siv tshuab, khoom thiab cov ntaub ntawv kuaj xyuas.
Siv plaub lub rooj txiav txim siab seb KGB110A haum
KGB110A yog nyob rau hauv daim ntawv teev npe luv thaum plaub lub rooj pov thawj kaw. Ua ntej, cov pwm haum rau platen, hnab ntawv, thickness ntau thiab txav. Qhov thib ob, lub taub hau xaiv tuaj yeem xa cov parison tag nrho nrog kev tswj hwm ntau yam. Thib peb, extrusion rov qab txhawb lub hom phiaj voj voog nrog cov khoom siv tiag tiag. Plaub, lub Hoobkas tuaj yeem muab cov khoom siv hluav taws xob uas xav tau thiab tuav.
Daim ntawv lo 160L tsis tuaj yeem hloov lub rooj vag. Ib feem ntev yuav ua tsis tau cov pwm kuaj. Ib qho hnyav tuaj yeem ua tsis tau qhov kev txhaj tshuaj. Lub voj voog luv luv tuaj yeem ua tsis tiav qhov kev kuaj rov qab. Lub Hoobkas uas txwv qhov siab yuav ua tsis tau qhov kev kuaj xyuas.
Txav mus rau hauv lub tshuab ntau yam thaum cov khoom thiab pwm me dua thiab lub platform loj dua ntxiv tsis muaj peev xwm siv tau. Txav mus lossis thov lwm qhov kev teeb tsa thaum txhaj tshuaj tag nrho, pwm qhov chaw lossis qhov xav tau clamp ntau tshaj qhov ua pov thawj. CovKGB100B 120L phau ntawv qhiamuab cov kev kuaj xyuas engineering uas nyob ib sab qis dua.
Ua tiav qhov kev xaiv nrog kos npe yuav tsum tau matrix. Txhua kab yuav tsum npe tus neeg yuav khoom tawm tswv yim, kev teeb tsa thiab cov ntaub ntawv pov thawj uas yuav ua pov thawj ua raws. Cov khoom tsis paub yuav tsum nyob twj ywm qhib tsis yog hloov nrog daim ntawv qhia kev xav.
Lub tshuab qauv yog ces qhov tshwm sim ntawm cov ntaub ntawv cov khoom. Qhov kev txiav txim ntawd muab tus tsim pwm tsim, tshuab tsim thiab tus neeg yuav khoom ib txheej ntawm qhov tseeb los ua haujlwm los ntawm.
Cov lus nug uas nquag nug
Cov khoom dab tsi yog KGB110A 160L tshuab moulding tshuab npaj rau?
Kinggle cov khoom nplooj ntawv teev cov thoob, rooj tog, ntab, pontoons, cov khoom ua si, nws pib qhov chaw thiab cov teeb meem tsheb. Cov no yog cov tsev neeg thov. Cov khoom tshwj xeeb tseem xav tau kev kuaj pwm kom haum, tag nrho parison loj, clamp thov, khoom siv, cua txias thiab tshem tawm.
Vim li cas kuv thiaj li yuav tsum tau xa ib daim qauv ntawm lub cev nrog rau daim duab kos?
Cov duab kos txhais cov duab geometry tau pom zoo, thaum cov qauv pab pawg neeg ua haujlwm tshawb xyuas qhov hnyav, sib cais kab, luas, phab ntsa faib thiab tuav. Siv ob qho tib si thaum ua tau. Daim duab kos thiab sau ntawv yuav tsum tswj xyuas yog tias tus qauv txawv ntawm qhov tsim tam sim no.
Puas yog 320 pcs / h cov khoom tsim tawm ntawm KGB110A?
Tsis yog KGB110A nplooj ntawv sau 320 pcs / h raws li lub voj voog qhuav. Kev lees txais yuav tsum muaj xws li extrusion rov qab, parison tsim, tshuab, txias, tshem tawm, trimming, tsis lees paub thiab suav nres nrog cov pwm tsim thiab cob.
Puas yog 15 kg tiav PE ib feem khiav ntawm KGB110A?
Lub rooj rau pej xeem qhia txog 9 (15) kg raws li PE accumulator-qhov hnyav siv, tsis muaj peev xwm ua tiav. Gross parison mass muaj xws li cov khoom thiab tag nrho cov flash los yog trim. Paub meej tias lub taub hau xaiv, resin hauv paus thiab kev khiav hauj lwm margin, tom qab ntawd ua pov thawj qhov tshwm sim hauv cov khoom sim.
Puas yog tus qauv KGB110A ua ntau txheej khoom?
Cov lus piav qhia ntawm cov khoom hais txog ib txheej txheej thiab ntau txheej kev daws teeb meem, thaum pej xeem cov lus teev ib tus ntsia hlau thiab ib lub tshuab extruder. Ib txoj haujlwm ntau txheej xav tau ib qho kev sib cais-txoj kev kos duab, daim ntawv extruder, lub taub hau teeb tsa, cov txheej txheem sib piv thiab cov ntawv kho dua tshiab.
Dab tsi yuav tsum suav nrog hauv KGB110A kev nug?
Xa cov khoom kos duab, qauv duab, qhov ntev, qhov hnyav, daim ntawv qhia phab ntsa, resin, trim kwv yees, kev ntsuam xyuas zoo, lees txais cov hom phiaj, cov ntaub ntawv pwm thiab cov khoom siv hluav taws xob. Kinggle tuaj yeem lees paub lub taub hau, pwm qhov chaw, kev npaj extrusion thiab kev npaj txais.
Xa cov khoom pov thawj, tsis yog ib lub ntim xwb
Qhia tawm cov qauv ntaub ntawv, cov ntaub ntawv pwm, tso zis lub hom phiaj thiab cov nroj tsuag tej yam kev mob nrog Kinggle. Pab pawg neeg ua haujlwm tuaj yeem siv cov lus tseeb no kom paub meej txog KGB110A kev teeb tsa thiab txhais cov khoom raws li kev sim.
Thov KGB110A configuration tshuaj xyuasCov peev txheej thiab tshuaj xyuas hauv paus
- Kinggle, 160L Accumulate Tshuab Moulding Tshuab, qauv KGB110A. Cov khoom muag, cov lus qhia tshwj xeeb thiab cov ntawv teev npe, txheeb xyuas lub Cuaj Hlis 15, 2026.
- Kinggle Kev Muag Khoom. Cov ntaub ntawv thov ntawm cov khoom lag luam thiab tau hais txog kev tshuaj xyuas kev ua haujlwm, kuaj xyuas lub Cuaj Hlis 15, 2026.
- Moog DigiPack III phau ntawv qhia tuav los ntawm Kinggle. Khaws cov ntaub ntawv cov khoom thiab programmed phab ntsa-thickness tswj rau accumulator lossis cov tshuab txuas ntxiv.
- EUROMAP 46.2, Extrusion Tshuab Moulding Tshuab, Kev Txiav Txim ntawm Cov Khoom Siv Hluav Taws Xob. Version 1.0, Lub Ib Hlis 2014.
