30L ACTRACULATOR TSHUAB Moulding Tshuab

Model:KGB80AP

KGB80AP yog ob chav 30L accumulator tshuab tshuab moulding tshuab muaj xim txheej ob npaug lossis ob chav xim tshuab moulding tshuab tsim. Cov cuab yeej no yog rau cov xim cov khoom lossis zoo tagnrho rau ob npaug rau txheej / cuab yeej siv tshuab xws li, cov cuab yeej siv no ua kom muaj kev cia siab ntev.

Ntim: 30LQhov hnyav: 13T

Xa lus nug

Product Description

Tus Qauv KGB80Anc qauv, tsis tsuas yog ib txwm 30l accumulator tshuab moulding tshuab, tab sis kuj muaj ob chav extrusion system yuav haum ob txheej lossis ob chav xim ntau lawm yuav tsum muaj.
Suav nrog Moog 100 thickness maub los, neeg hlau caj npab, thiab hauv qab tshuab System, txhim kho kev tsim khoom thiab cov khoom lag luam zoo. Qhov no ntau yam tshuab yog qhov zoo tagnrho rau ntau yam kev siv, suav nrog cov kuab tais lim Tshuab daws teeb meem, yas extrusion tshuab moulding tshuab txheej txheem ,.

Cov lus qhia

muaj pes tsawg tus lej	Cov khoom siv PE, PP, ABS ...	Pwm kaw cov roj kheej kheej (tib tog kheej kheej)
muaj pes tsawg tus lej	Cov khoom siv PE, PP, ABS ...	TSHUAB qauv: KGB80AP
Cov lus qhia
1	Max Ntim Peev Xwm	L
2	Tso Tawm (Lub voj voog qhuav)	650 PC / hr
3	Tshuab Dimension (L × W × h)	4.7 m x3.5 m x 4 m
4	Tshuab qhov hnyav	13T
Clamping chav tsev
1	Clamping yuam	215 kn
2	Pwm Platen Loj (W × h)	750 hli × 860 hli
3	Daim phiaj qhib Toke	350 hli -850 hli
4	Platen Tsiv stroke	370 hli
5	Max Pwm Loj (W × h)	520 hli × 860 hli
6	Pwm Thickness	360 mm - 420 hli
Hwjchim
1	Servooil twj tso kua mis muaj zog	11 kw
2	SERVO TWJ TSO KUA MIS	80 L / min
3	Hau pliaj	0.8 MPa
4	Kev Siv Cua Cua	0.7 m² / mi
5	Cua txias dej siab	0.3 MPa
6	Kev Siv Dej	70 L / min
7	Qhov nruab nrab hluav taws xob siv	27 KWS 37th
Extruder Chav
1	Ntsia Hlau taub	2 * 70 hli
2	Ntsia hlau L / d piv	24 L / D
3	Melting capacit rau HDPE	120 kg / hr -140 kg / hr
4	Cov naj npawb ntawm thaj chaw ua cua sov	4 cheeb tsam
5	NTSIA HLUB cua kub	15.6 kw
6	Ntsia hlau fanpower	0.5 kw
7	Extruder Lub Zog Muaj Zog	2 * 22 kw
Tuag Lub Taub Hau
1	Cov naj npawb ntawm cov hluav taws xob	5 Cheeb Tsam
2	Cua sov fais fab	22.8 kw
3	Maxdie-tus pin inch	220 hli
4	Accumulator muaj peev xwm	5 l
5	(PE) Tsoos Kev Nyuaj Siab	3.75 kg

Nta thiab Qhov Zoo

Tus qauv no yog qhov chaw qhib thiab kaw cov pwm, siv ob npaug rau ob npaug synchronous zaj duab xis kaw kaw lub puab tsaig pwm
Cia Cia Lub Tshiv Ncauj Tuag Lub Taub Hau Series
Tshaj Plaws Ntim 30L
Haum forchemical jerry cants, cov cuab yeej siv hluav taws xob, thiab roj tso tsheb hlau luam, thiab lwm yam.
Qhov txawv tshwj xeeb yog tias nws tau tswj hwm los ntawm ib hydraulic servo system kom ua tiav ceev kev ua teb thiab muaj zog ua haujlwm.

Chaw thov

Toolbox, JerryCan, Stud Chim

Cov FAQ

1. Ntau npaum li cas ntawm kev sib sau ua qauv tshuab moulding tshuab?

Vim yog cov khoom sib txawv, lub tshuab tuaj yeem muaj lub cev hlau / hauv qab tshuab system / Foob ntaus ntawv, thiab lwm yam. Thov qhia koj cov khoom lag luam rau koj, ces peb muab cov tshuaj rau kev siv.

2. Kuv tuaj yeem xaiv tus qauv zoo li cas?

Rau li niaj hnub fwj / barrels thiab lwm yam pob khoom, tsuas yog paub meej tias lub max ntim ntawm lub tshuab. Rau lwm cov khoom lag luam tshwj xeeb, xav tau kev txiav txim siab platen / extrusion / Hwj chim thiab lwm yam, thov hu rau peb kom tau daws cov tshuaj zoo.

3. Piv nrog lwm hom, vim li cas kuv xaiv Kinglle tshuab moulding tshuab?

Kinged koom rau hauv tshuab moulding Txij xyoo 2008, peb kev paub tuaj yeem txhawb nqa tshiab Cov neeg yuav khoom kom tau txais cov kab ntau lawm thiab ua tiav kev nqis peev rov qab los. Nyob rau 20 xyoo dhau los, peb tau tsim dav dav thiab tsim qauv ywj pheej, ua tiav ruaj khov thiab kev tsim khoom zoo.

4. Koj tau lees paub ntawm lub tshuab zoo?

Peb yuav siv cov tshuab ntsuas siab ua ntej xa khoom kom paub tseeb tias cov kev tsim khoom yog ruaj khov. Thiab muab 1-xyoos lav txij li lub tshuab tuaj txog koj lub Hoobkas. Yog tias xav tau, kuj tuaj yeem muab daim ntawv pov thawj SGS.

5. Koj puas muab kev cob qhia kev saib xyuas kev saib xyuas lossis kev ua txhaum kev txhaum?

Yog lawm, peb tsis tsuas yog muaj cov ntaub ntawv txij nkawm tab sis kuj muaj cov ntaub ntawv txuj ci / Cov yeeb yaj kiab los daws cov teeb meem.
Lub khoos kas TSHUAB muaj lub tswb ceeb toom, uas tuaj yeem pab tau nyob rau hauv Kev daws teeb meem teeb meem

6. Koj tau txais kev pab cuam tom qab twg?

Peb tuaj yeem xa cov kws ua choj rau koj lub hoobkas los pab koj nruab thiab tsheb ciav hlau, lub ntsiab Cheebtsam tuaj nrog lub sijhawm 1-2 xyoo lav, thiab qhov chaw tsis yooj yim tuaj yeem yog hloov dawb hauv ib xyoos.
