Xaiv Kinggle KGB90A thaum cov khoom pom zoo tuaj yeem siv cov ntawv luam tawm ib leeg-extruder layout thiab tsis xav tau KGB90AP ob qhov dej ntws, tom qab nws cov khoom siv, cov zis thiab cov khoom kuaj tau raug txhais.Xaiv KGB90AP thaum cov khoom specification tiag tiag hu rau ob-txheej los yog ob-xim extrusion, vim hais tias nws cov nplooj ntawv cov khoom tam sim no teev ob 70 mm screws thiab ob lub kwj ntawm cov khoom yuav tsum tau soj ntsuam nyias. Ua ntej ob qho kev xaiv, paub meej tias lub hnab ntawv pwm, tag nrho parison pawg, resin, phab ntsa qauv, lees txais cov khoom siv thiab cov khoom siv hluav taws xob tawm tsam qhov ua tiav es tsis yog cia siab rau 60L muaj peev xwm daim ntawv lo ib leeg.
Tsib qhov kev txiav txim siab ua ntej thov kev hais lus
- Ib qho dej ntws los yog ob
- Qhov siab tshaj plaws tag nrho parison pawg
- Ua tiav pwm qhov loj me thiab qhov cuam tshuam
- Txais cov zis nrog cov khoom tiag
- Tshuab thiab tag nrho-kab siv hluav taws xob Scope
KGB 90A
Tshaj tawm nrog ib lub 90 hli ntsia hlau thiab 45 kW extruder lub cev muaj zog. Pib ntawm no rau ib lub tswv yim khoom lag luam, raws li kev pom zoo ntawm qhov project.
KGB 90 PAB
Tshaj tawm nrog ob lub 70 hli screws thiab ob lub 22 kW extruder motors. Nws lub hom phiaj tau teev tseg yog ob txheej txheej lossis ob-xim ntau lawm.
| Tshaj tawm yam khoom | KGB 90A | KGB 90 PAB | Xaiv lub ntsiab lus |
|---|---|---|---|
| Muaj peev xwm ntim siab tshaj plaws | 60 L | 60 L | Nominal peev tsis ua pov thawj ib feem haum. |
| Extruder kev npaj | Ib tug 90mm ntsia hlau | Ob lub qhov 70 mm | Qhov no yog lub ntsiab qauv sib txawv rau phab ntsa thiab xim qauv. |
| Extruder lub cev muaj zog | 45 kW ua | 2 x 22 kW | Kev ntsuam xyuas lub cev muaj zog tsis yog cov khoom siv zog. |
| Tshaj tawm HDPE melting muaj peev xwm | 130-160 kg / h | 130-160 kg / h | Paub meej tias muaj peev xwm nrog qhov tseeb resin thiab tag nrho parison thov. |
| Accumulator muaj peev xwm | 6.6l ua | 6.6l ua | Txheeb xyuas qhov ntim thiab ntim tawm tsam tag nrho parison. |
| Tshaj tawm PE accumulator hnyav | 4, 95kg | 4, 95kg | Qhov hnyav ib leeg tsis suav nrog flash, tails thiab cov txheej txheem nyiaj pub dawb. |
| Clamping quab yuam | 280kn ua | 280kn ua | Thaj chaw thiab cov txheej txheem xav tau tseem xav tau kev tshuaj xyuas. |
| Cov pwm loj tshaj plaws, W x H | 700 x 980 mm | 700 x 980 mm | Kev sib dhos ua tiav pwm yuav tsum haum rau ob qhov ntev. |
| Pwm thickness ntau | 460-550 hli | 460-550 hli | Xws li inserts, rov qab daim hlau thiab mounting cov ntsiab lus. |
| Tshuab loj, L x W x H | 5.45 x 3.5 x 4.2 m | 5.45 x 3.5 x 4.2 m | Qhov no yog lub hnab ntawv tshuab, tsis yog tag nrho cov khoom ntawm tes. |
| Tshuab hnyav | 14 ib t | 15t ib | Siv qhov kawg ntawm kev npaj rau lub hauv paus thiab tuav. |
Source: tam sim no KinggleKGB90A khoom nploojthiabKGB90AP khoom nplooj, tshawb xyuas lub Cuaj Hlis 9, 2026. Cov duab tau luam tawm cov ntawv pov thawj, tsis yog qhov lav rau txhua qhov kev teeb tsa.
Thawj qhov kev txiav txim siab yog cov qauv phab ntsa, tsis yog 60L daim ntawv lo
Ob lub qauv nqa tib lub nominal 60L muaj peev xwm. Daim ntawv qhia ntawd tsis ua rau lawv hloov pauv tau. KGB90A cov khoom lag luam cov lus teev ib qho 90 hli ntsia hlau. KGB90AP cov lus teev ob lub 70 hli screws. Kinggle hais tias ob-extrusion system yog npaj rau ob txheej lossis ob-xim ntau lawm.
Pib nrog cov khoom kos duab. Kos txhua qhov xav tau ntawm phab ntsa txheej, xim cheeb tsam thiab cov khoom siv. Qhia vim li cas txhua tus muaj. Qhov thib ob extruder yog tsim nyog los ntawm cov khoom yuav tsum tau ua. Nws yuav tsum tsis txhob muab ntxiv xwb vim hais tias ib tug complex tshuab suab ntau muaj peev xwm.
Rau ib qho khoom lag luam, KGB90A yog qhov yooj yim tshaj tawm cov qauv tsim. Lub tswv yim kawg tseem xav tau cov ntaub ntawv thiab cov cuab yeej tshuaj xyuas. Nplooj ntawv teev PE, PP thiab ABS raws li tsev neeg cov ntaub ntawv, tab sis daim ntawv teev npe tsis ua pov thawj tias txhua qib yuav ua tiav ntawm cov khoom siv tib yam. Melt cwj pwm, cov khoom geometry thiab kev lees paub qhov kev xeem tseem nyob hauv qhov project inputs.
Rau cov txheej txheem ob txheej lossis ob-xim khoom, KGB90AP muab ob qhov kev tshaj tawm extrusion ntws. Cov lus hais yuav tsum mus ntxiv. Nws yuav tsum txheeb xyuas cov resin los yog xim dab tsi pub rau txhua tus kwj dej. Nws tseem yuav tsum tau hais txog lub hom phiaj txheej kev sib raug zoo, kev pib ua haujlwm thiab kev npaj tshuaj ntsuam xyuas. Ob lub extruders tsim muaj peev xwm. Lawv tsis txhais ib lub phab ntsa tiav los ntawm lawv tus kheej.
Tsis txhob cuam tshuam cov khaubncaws sab nraud povtseg nrog cov qhov hluav taws xob tuag lossis pwm kab noj hniav. Ib txheej khiav los ntawm cov khoom siv phab ntsa. Lub qhov hluav taws xob tuag ua ib lub parison. Ib kab noj hniav tsim ib feem. Kinggle covtaub hau, kab noj hniav thiab txheej txheej qhiacais cov suav ntawd. Muab txhua tus suav rau ntawm nws tus kheej RFQ kab.
Qhov ob lub rooj tshaj tawm tau hais txog lub platform sib koom
Cov ntxhuav qauv tam sim no qhia ib lub hnab ntawv uas muaj ntau. Ob daim ntawv teev 280 kN clamping quab yuam thiab 960 x 980 mm pwm platen. Ob leeg qhia qhov siab tshaj plaws pwm loj ntawm 700 x 980 mm. Cov luam tawm pwm thickness ntau yog 460 txog 550 hli. Cov npe accumulator muaj peev xwm yog 6.6 L, nrog PE accumulator hnyav ntawm 4.95 kg.
Qhov zoo sib xws no ua rau cov txheej txheem extruder pom ntau dua. KGB90A siv ib lub 90 hli ntsia hlau nrog cov npe 45 kW extruder lub cev muaj zog. KGB90AP siv ob lub 70 hli ntsia hlau nrog ob lub cav 22 kW. Ob nplooj ntawv luam tawm HDPE yaj-muaj peev xwm ntawm 130 txog 160 kg / h.
Tsis txhob ntxiv ob lub peev xwm ntawm KGB90AP tshwj tsis yog lub rooj qhia meej meej nthuav tawm cov khoom sib cais. Tsis yog. Cov ntawv tshaj tawm twb piav qhia txog tus qauv. Ob chav extruder layout tuaj yeem faib tag nrho cov yaj ntawm cov kwj deg, tab sis cov txheej txheem pom zoo txiav txim siab txhua tus kwj qhov kev thov tiag tiag. Lub Hoobkas xav tau qhov piv txwv ua ntej sizing resin tuav thiab khiav kev sim.
Lub tshuab qhov ntev kuj tau luam tawm raws li qhov sib npaug ntawm 5.45 x 3.5 x 4.2 m. Cov npe hnyav hloov ntawm 14 t rau KGB90A rau 15 t rau KGB90AP. Qhov sib txawv ntawm ib-tonne yog qhov tseem ceeb rau kev npaj ua ntej. Nws tsis txaus rau lub hauv paus kawg, kev nqa lossis kev npaj thauj khoom.
Ob lub rooj kuj muaj tib lub voj voog qhuav qhuav. Kho nws raws li kev siv tshuab-tsim lus nkaus xwb. Nws tsis txheeb xyuas lub thawv ntsuas, resin, qhov hnyav, lub sijhawm txias lossis tsis kam lees txoj cai. Ib tsab xov xwm khoom lag luam yuav tsum ua kom qhov kev txwv tsis pub dhau los ntawm kev xa cov kab catalog rau hauv kev cog lus ntau lawm.
Qhov twg KGB90A yog qhov pib ncaj qha ntau dua
KGB90A yog tus qauv ib leeg-extruder hauv qhov kev sib piv no. Nws nplooj ntawv luam tawm teev ib lub 90 hli ntsia hlau, 24 L / D piv thiab 45 kW extruder lub cev muaj zog. Kinggle tseem teev cov MOOG 100 thickness maub los, neeg hlau caj npab thiab hauv qab-blowing system raws li ib feem ntawm tus qauv piav qhia.
Qhov kev teeb tsa no yog qhov pib ua tau zoo thaum cov khoom pom zoo siv ib qho dej ntws. Cov ntawv thov uas tau teev tseg los ntawm Kinggle suav nrog cov ntim tshuaj, cov thoob ntim khoom, cov tso dej tawm sab nraum zoov, lub tsheb tso tsheb hlau luam, cov khoom ua si, tsheb qhov chaw, cov cuab yeej thiab cov teeb meem tsheb. Cov npe qhia qhov dav ntawm cov khoom. Nws tsis tau lees paub tias txhua yam khoom hauv cov pab pawg no haum rau ib qho pwm lossis ib daim ntawv qhia.
Xa qhov tseeb ua ntej xav tias haum. Lub 60L nqaim tank thiab 60L dav toolbox tuaj yeem muaj ntau qhov sib txawv. Lawv cov pwm tuaj yeem sib txawv ntawm qhov dav, qhov siab thiab tuab. Kov, sib sib zog nqus draws, inserts thiab parting kab cuam tshuam qhov yuav tsum tau parison thiab clamp load. Qhov siab tshaj plaws ntawm cov khoom ntim tsuas yog ib qho kev ntsuam xyuas tus nqi xwb.
Kev npaj ib leeg-extruder kuj ua rau cov khoom siv yooj yim dua los txhais. Muaj ib lub ntsiab resin kwj kom qhuav, pub, xim thiab ntxuav. Qhov ntawd tsis tshem tawm cov txheej txheem ua haujlwm. Resin hloov, hloov xim thiab regrind cov cai tseem cuam tshuam rau kev pib thiab hloov pauv. CovHDPE thiab PP phau ntawv qhiapiav qhia vim li cas cov npe khoom ib leeg tsis teeb daim ntawv qhia.
Xaiv KGB90A tsuas yog tom qab cov khoom xav tau txhawb nqa nws. Yog tias tus neeg yuav khoom tom qab ntxiv cov txheej thib ob lossis cov xim sib cais pom, qhov kev hloov pauv tuaj yeem cuam tshuam rau tag nrho extrusion thiab tuag-lub taub hau pob. Nws yog pheej yig dua los daws cov qauv phab ntsa ua ntej lub tshuab tsim yog khov.
Dab tsi KGB90AP ntxiv, thiab nws tseem xav tau dab tsi los ntawm tus neeg yuav khoom
Kinggle piav qhia txog KGB90AP raws li tus qauv ob-extrusion rau ob txheej txheej lossis ob-xim ua haujlwm. Nws cov lus tam sim no teev ob 70 mm screws thiab ob lub 22 kW extruder motors. Cov ntawv tshaj tawm lub peev xwm siab tshaj plaws, cov ntaub ntawv clamping, lub hnab ntawv pwm thiab cov duab accumulator phim lub rooj KGB90A.
Qhov ntxiv extrusion kwj yog qhov sib txawv. Nws tso cai rau peb tes num pub ob teev cov dej ntws mus rau hauv lub taub hau tuag. Cov kwj deg no tuaj yeem sawv cev rau ob xim lossis ib txheej txheej txheej tsim. Tus neeg yuav khoom yuav tsum muab cov khoom ua khub thiab kev sib raug zoo ntawm lawv. Compatibility yuav tsum tsis txhob xav tias los ntawm cov lus "ob txheej."
Txheej tswj kuj xav tau ib txoj kev tshuaj xyuas. Txiav txim siab seb lub Hoobkas puas yuav kuaj xyuas tag nrho cov phab ntsa tuab, ib tus neeg txheej txheej, xim ciam teb, zoo li lossis cov khoom siv tshwj xeeb kev ntsuas. Qhia qhov twg yuav muab faib los yog ntsuas. Cov txiaj ntsig dhau los xav tau kev kos duab lossis kev tswj hwm, tsis yog kev xav pom ntawm lub tshuab.
Cov nplooj ntawv KGB90AP tau tshaj tawm kuj muaj npe lub thawv khoom, ntim tshuaj lom neeg thiab cov khoom ua si raws li kev siv. Txhua tus tuaj yeem muab qhov xav tau sib txawv ntawm cov duab phab ntsa thiab xim tso rau. Ib lub thawv cuab yeej yuav muaj cov yam ntxwv sib sib zog nqus thiab thaj chaw dav dav. Kev ntim tshuaj yuav xav tau cov khoom siv thiab kev ua haujlwm tshwj xeeb. Cov khoom ua si tuaj yeem nqa cov tsos thiab xim-kho raws li xav tau. Lub tswv yim tshuab yuav tsum ua raws li qhov tseeb.
Kinggle-hostedMOOG DigiPack III manualpiav qhia tias accumulator-tshuab phab ntsa profiles muaj feem xyuam rau accumulator txoj hauj lwm thaum thawb tawm. Qhov ntawd txhawb nqa qhov profile tso rau hauv parison. Nws tsis cia li tswj tus neeg yuav khoom txheej piv. Lub extrusion thiab tuag-lub taub hau tsim yuav tsum hais txog qhov yuav tsum tau cais.
Ib qho 60L cov khoom tseem yuav tsum tau ua kom haum cov pwm thiab accumulator
Nominal ntim yog qhov kev xeem tsis zoo kawg nkaus. Ob yam khoom hollow tuaj yeem tuav tib lub ntim thaum xav tau pwm txawv heev. Pib nrog qhov siab tshaj plaws qhov dav, qhov siab thiab qhov tob. Ntxiv cov kab sib cais, pinch-tawm, flash hnab ris, caj dab lossis hauv qab-tshuab interface, ntxig, sib txuas ua kom txias thiab mounting daim hlau.
Sib piv cov pwm ua tiav nrog lub tshuab luam tawm qhov rais. Ob nplooj ntawv 60L sau cov pwm loj tshaj plaws ntawm 700 x 980 hli thiab thickness ntau ntawm 460 txog 550 hli. Lub platen yog teev ntawm 960 x 980 mm. Cov duab no tso cai rau kev tshuaj xyuas ntxov. Lub tshuab pom zoo thiab cov duab kos pwm yuav tsum paub meej tias qhov kawg interface.
Tom ntej no mus saib parison. Gross parison mass muaj xws li cov khoom tiav, nyem, tails thiab cov txheej txheem cov ntaub ntawv raug ntes thaum tsim. Ob nplooj ntawv khoom sau npe 4.95 kg PE accumulator hnyav. Tsis txhob muab tus lej ntawd piv nrog qhov hnyav tag nrho ib leeg. Siv qhov kev txhaj tshuaj tag nrho thiab paub meej tias cov khoom siv tiag tiag.
Lub parison kuj yuav tsum ncav cuag qhov ntev thiab cov duab ua ntej lub ntiajteb txawj nqus los yog txias distorts nws. Phab ntsa programming faib cov khoom raws li qhov ntev. Sib sib zog nqus fab, tuav thiab dav seem tuaj yeem ncab lub parison sib txawv. Kinggle covparison programming qhiaqhia tau hais tias qhov profile yuav tsum tau kuaj xyuas li cas rau qhov ntsuas ntawm phab ntsa.
Thaum kawg, tshuaj xyuas qhov xav tau clamp thiab pwm qhib. Qhov projected cheeb tsam, tshuab siab thiab ib feem geometry cuam tshuam txoj kev load. Ntxig thiab tshem tawm ib feem cuam tshuam qhov chaw qhib. Covextrusion tshuab mould tsim phau ntawv qhiamuab ib daim ntawv teev npe puv npo.
Tsis txhob muag lub voj voog qhuav raws li cov khoom tiav tiav
Ob nplooj ntawv khoom tam sim no sau "500 PC / HR" raws li cov khoom tsim tawm qhuav. Daim ntawv lo tseem ceeb. Lub voj voog qhuav tsis ua pov thawj tias tus qauv twg tuaj yeem ua 500 txais 60L cov khoom hauv ib teev. Nws tsis suav nrog qhov txheeb xyuas qhov hnyav, qhov hnyav tag nrho, cov khoom siv, phab ntsa tuab, qhov yuav tsum tau ua kom txias lossis cov txheej txheem qis.
Cov zis tiag tiag pib nrog lub voj voog ntau lawm. Kev sib sau thiab parison push-out yuav tsum phim pwm kaw. Tshuab, cua txias, tso pa tawm, qhib thiab tshem tawm ib feem yuav tsum tiav. Trimming thiab downstream tuav yuav tsum ua kom nrawm. Ib feem uas tsis lees paub tsis yog nyob rau hauv cov zis tau txais.
Cov luam tawm HDPE melting-muaj peev xwm ntau yog lwm tus ciam teb. Ob nplooj ntawv sau 130 txog 160 kg / h. Sib piv qhov ntau nrog cov khoom xav tau tag nrho, tsis tiav qhov hnyav ib leeg. Tag nrho cov kev xav tau ib teev suav nrog txhua qhov parison tivthaiv thiab tus nqi uas tau npaj tseg. Qhov tseeb resin thiab txheej txheem txheej txheem tuaj yeem hloov qhov tshwm sim.
Siv Kinggle'slub voj voog-lub sij hawm qhiatxhawm rau txheeb xyuas qhov kev txwv txwv. Tom qab ntawd suav qhov lees txais thoob plaws qhov kev khiav haujlwm ruaj khov. Sau ib feem qhov hnyav, phab ntsa faib, qhov ntev thiab qhov yuav tsum tau ua rau kev sim ua haujlwm. Lub tshuab nrawm nrawm muaj nuj nqis me ntsis thaum cov khoom xav tau txias dua lossis cov kab tsis lees txais qhov chaw.
Lub zog yuav tsum siv tib qhov lees txais-tso tawm tus lej. Ob lub rooj rau pej xeem sau npe 35 txog 45 kW ntau yam raws li kev siv hluav taws xob nruab nrab. Kilowatts piav qhia lub zog nruab nrab, tsis yog lub zog ib feem. Covphau ntawv qhia kev ntsuas lub zogpiav qhia yuav ua li cas ntsuas kWh rau ib qho khoom lees paub. Khaws cov txiaj ntsig ntawd khi rau qhov kev sim tiag tiag.
Lub xovtooj ntawm tes ntau lawm yog loj dua lub hnab ntawv tshuab luam tawm
Ob nplooj ntawv 60L luam tawm tib lub tshuab qhov ntev: 5.45 m ntev, 3.5 m dav thiab 4.2 m siab. Qhov ntawd yog ib qho txiaj ntsig thawj zaug. Nws tsis qhia cov kev pabcuam aisles, cov khoom siv, cov haujlwm ua haujlwm, kev tuav pwm, kev tso tawm lossis cov khoom siv hauv qab.
Tsim cov cell nyob ib ncig ntawm cov khoom ntws. Kos qhov twg resin nkag mus thiab qhov chaw tiav lawm. Tso cai rau qhov chaw rau cov neeg hlau, trimming, tshuaj xyuas thiab cov khoom tsis lees paub. Qhia cov pwm-hloov txoj kev. Khaws nkag mus rau cov cua sov, hydraulics, lub taub hau tuag thiab tswj txee. Kev npaj dav dav kawg yuav tsum txheeb xyuas cov kev sib tshuam no.
Cov khoom siv hluav taws xob kuj muaj nyob rau hauv cov kev xaiv xaiv. Nug rau qhov kawg txuas nrog load, muab qhov hluav taws xob, kev xav tau ntawm tshuab-inlet cua thiab cua txias-dej xav tau. suav nrog txhua pab pawg hauv zos. Tsis txhob tsim cov nroj tsuag los ntawm cov qauv zoo sib xws lub rooj. Cov kev xaiv thiab kev tsim hluav taws xob hauv zos tuaj yeem hloov lub pob kawg.
Kinggle covdaim ntawv qhia txog kev siv hluav taws xobcais cov kev txuas txuas ntawm kev ua haujlwm xav tau. Nws tseem npog compressed-cua ntws, cua txias thiab layout. Siv nws nrog daim ntawv siv hluav taws xob thiab qhov kawg tshuab kos duab. Lub chaw npaj yuav tsum tau pom zoo ua ntej lub tshuab nkoj.
Txheeb xyuas txoj kev ntsug kom zoo zoo li hauv pem teb. Qhov siab tshaj tawm tsis suav nrog txhua qhov kev nqa nqa lossis qhov chaw teeb meem. Txheeb xyuas qhov rooj, lub ru tsev qauv, kev nkag mus rau crane thiab txoj kev siv rau kev tuav pwm. Qhia kev tu lub platform thiab qhib kev tiv thaiv ntawm qhov layout. Lub tshuab tuaj yeem haum rau hauv lub tsev thiab tseem nyuaj rau nruab lossis kev pabcuam.
Ua kom tiav qhov kev tshuaj xyuas nrog cov kab hauv qab. Ib feem loj xav tau chav kom ruaj khov, luas thiab txav mus yam tsis muaj kev puas tsuaj. Paub meej tias tus neeg hlau poob taw tes, conveyor dav thiab qhov chaw soj ntsuam. Yog hais tias tus txheej txheem rov qab flash rau lub grinder, khij txoj kev ntawd thiab. Cov ntsiab lus no feem ntau txiav txim siab qhov twg lub tshuab tuaj yeem zaum.
Tsim cov RFQ ib ncig ntawm yim daim ntawm cov khoom pov thawj
Ib qho qauv thov yam tsis muaj ib feem pob tawm qhov kev txiav txim siab loj tshaj plaws qhib. Kinggle covkev muag khoomnug cov khoom duab lossis kos duab, qhov hnyav, qhov loj me, cov khoom siv, thickness, cov zis thiab cov kev xav tau ntawm cov tshuaj. Rau qhov kev txiav txim siab KGB90A thiab KGB90AP, npaj cov ntaub ntawv hauv qhov kev txiav txim no.
- Xa cov kev tswj qhov kos duab.suav nrog tag nrho qhov ntev, lub caj dab lossis cov ntsiab lus sib txuas, kev txwv kev sib cais thiab kev hloov kho tshiab kawg.
- Qhia tag nrho thiab ua tiav pawg.Cais cov khoom tiav qhov hnyav ntawm flash, tails thiab lwm yam khoom siv.
- Txhais txhua yam khoom siv.Muab cov qib resin, tus neeg muag khoom, xim, txoj cai regrind thiab ib qho kev sib raug zoo ntawm cov kwj deg.
- Piav txog cov qauv phab ntsa.Kos ib kwj, ob txheej lossis ob xim. Ntxiv cov txheej txheem tshuaj xyuas thiab kev lees txais.
- Muab cov pwm pob.Xa qhov kawg qhov dav, qhov siab, tuab, qhov hnyav, qhov cua txias, cov ntsiab lus mounting, ntxig thiab tshuab tshuab.
- Teem tau txais cov zis.Txhais cov khoom muag hauv ib teev, npaj hloov pauv, tsis lees txais kev kho mob thiab cov txheej txheem qis qis uas yuav tsum ua kom nrawm.
- Sau cov xwm txheej ntawm lub Hoobkas.Xws li voltage, zaus, compressed cua, dej txias, qab nthab qhov siab, lifting access thiab muaj nyob rau hauv pem teb.
- Pom zoo rau qhov kev sim.Lub npe ntawm cov resin, pwm, lub sijhawm kuaj, kev kuaj xyuas zoo, suav cov zis, lub zog ciam teb thiab cov ntaub ntawv xav tau ua ntej txais.
Nug cov lus teb uas cais cov qauv qauv cov ntaub ntawv los ntawm cov ntaub ntawv tshwj xeeb. Cov lus txheej txheem pab piv rau lub platform. Daim ntawv cog lus thev naus laus zis yuav tsum piav qhia txog kev teeb tsa kev txiav txim. Khaws cov lej hloov kho ntawm cov khoom kos duab, kos duab pwm, daim ntawv siv hluav taws xob thiab kev npaj txais.
Siv covHoobkas lees txais kev xeem ntawv qhialos txhais kev khiav. Yog tias cov khoom lag luam ntsig txog lub zog yog ib feem ntawm qhov kev txiav txim siab, EUROMAP 46.2 muab cov qauv ntsuas rau lub tshuab muab, pwm thiab cov khoom teev tseg. Txoj kev kuj xav kom cov khoom ua tau raws li cov neeg siv khoom xav tau.
Kinggle covnplooj ntawv downloadmuab parameter tables thiab controller cov ntaub ntawv rau kev tshuaj xyuas. Paub meej tias txhua daim ntawv sib tw ua qauv kawg thiab cov pob tswj. Ib phau ntawv qhia rau lub tshuab zoo sib xws yog qhov muaj txiaj ntsig keeb kwm yav dhau, tab sis nws tsis override cov ntaub ntawv kev txiav txim.
Hais kom ob tog kos npe rau tib cov ntaub ntawv teev ua ntej kev tsim khoom pib. Ib qho kev hloov phab ntsa tuaj yeem hloov qhov kev xaiv extruder. Lub parison hnyav dua tuaj yeem hloov qhov kev tshuaj xyuas txhaj tshuaj. Lub pwm loj tuaj yeem hloov tshuab haum. Kev tswj xyuas kev kho kom tsis txhob muaj cov lus hais ntxov dhau los ua qhov kev lees txais zaum kawg los ntawm kev sib tsoo.
RFQ yuav tsum tau hais tias cov khoom twg tseem qhib. Cov piv txwv xws li cov qib resin zaum kawg, pwm kev sib txuas ua kom txias lossis kev ua haujlwm qis qis. Muab txhua qhov chaw qhib rau tus tswv thiab hnub kawg. Lub Hoobkas tuaj yeem cais cov ntaub ntawv tsim qauv tsim tawm los ntawm cov ntaub ntawv tseem xav tau kev pom zoo los ntawm tus neeg yuav khoom.
Xaiv tus qauv uas phim cov khoom pom zoo
KGB90A thiab KGB90AP sib koom ntau qhov kev txwv tsim tawm. Cov qauv xaiv yog li ntawd pib nrog extrusion architecture. Siv KGB90A ua qhov pib rau qhov pom zoo ib-kwj lub tswv yim. Siv KGB90AP thaum xav tau ob txoj kev extrusion rau txheej txheej lossis xim qauv.
Tsis txhob siv cov qauv complexity los hloov cov khoom txhais. Lub tshuab muab ob npaug rau-extrusion xav tau ob txoj kev tuav cov khoom siv, ib txoj kev pib pib thiab txheej txheej los yog xim tshuaj ntsuam xyuas. Yog tias cov khoom tsis xav tau cov haujlwm no, lawv ntxiv kev ua haujlwm yam tsis tau tsim cov txiaj ntsig tau txais txiaj ntsig.
Tsis txhob xaiv KGB90A nkaus xwb vim tias lub tshuab teev npe qis dua. Pwm haum, tag nrho parison xav tau thiab lees txais cov khoom tseem ceeb dua. Ib qho khoom lag luam ib leeg tseem tuaj yeem thov kom ceev faj txog phab ntsa programming, cua txias thiab kev tuav ib feem. Cov khoom sim yuav tsum ua pov thawj qhov ua tiav.
Yog tias tus neeg yuav khoom xav tau cov khoom lag luam yav tom ntej, sau lawv tam sim no. Tshawb xyuas cov pwm loj tshaj plaws thiab hnyav tshaj plaws parison. Kos rau yav tom ntej ob-txheej txheej lossis ob-xim yuav tsum tau ua. Tom qab ntawd txiav txim siab seb cov khoom siv ntxiv yog nyob rau hauv thawj qhov kev yuav khoom lossis kab tom qab. Khaws cov tswv yim yav tom ntej uas tsis tau lees paub cais tawm ntawm qhov kev lees paub tam sim no.
Ua ntej ua zaub mov xa tuaj, khiav qhov pom zoo nrog cov khoom pom zoo. Sau daim ntawv qhia, cov txiaj ntsig tau zoo, lees txais cov txiaj ntsig thiab kev siv hluav taws xob. Siv covstartup checklistrau kev ua haujlwm thiabchangeover phau ntawv qhiathaum tsev neeg cov khoom muaj xws li ob peb pwm los yog xim.
Cov lus nug uas nquag nug
Dab tsi yog qhov txawv ntawm KGB90A thiab KGB90AP?
Lub rooj KGB90A tam sim no teev ib lub 90 hli ntsia hlau thiab 45 kW extruder lub cev muaj zog. Lub rooj KGB90AP teev ob lub 70 hli screws thiab ob lub 22 kW motors. Kinggle piav qhia txog KGB90AP raws li kev xaiv ob-extrusion rau ob txheej lossis ob-xim khoom. Ntau qhov luam tawm tsim qhov ntev yog txwv tsis pub tib yam.
Puas yog 60L muaj peev xwm ntsuas txhais tau tias txhua 60L cov khoom yuav haum?
Tsis yog. Volume tsuas yog tus nqi kuaj thaum ntxov. Cov pwm tiav yuav tsum haum rau lub platen, qhov siab tshaj plaws pwm qhov ntev, thickness ntau thiab qhib kev npaj. Lub parison tag nrho yuav tsum haum rau qhov yuav tsum tau accumulator. Qhov projected cheeb tsam, clamp thov, inserts, cua txias thiab ib feem tshem tawm kuj xav tau kev tshuaj xyuas.
Cov luam tawm 500 daim ib teev twg tuaj yeem siv los ua cov khoom tsim tawm?
Tsis yog. Ob nplooj ntawv sau tias daim duab no yog cov khoom tawm los ntawm lub voj voog qhuav. Nws tsis txheeb xyuas cov khoom molded, resin, qhov hnyav, lub sijhawm txias, tsis kam lees txoj cai lossis kev teeb tsa hauv qab. Cov zis ntau lawm yuav tsum tau ntsuas raws li qhov tau txais thaum lub sij hawm pom zoo sim nrog cov khoom tiag thiab cov khoom siv.
Thaum twg tus neeg yuav khoom xaiv KGB90AP ob-extrusion qauv?
Xaiv KGB90AP thaum cov khoom pom zoo yuav tsum muaj ob lub kwj deg rau cov txheej txheem ob txheej lossis ob xim. Txhais ob qho tib si cov ntaub ntawv, lub hom phiaj kev sib raug zoo ntawm cov kwj deg thiab cov txheej txheem tshuaj xyuas. Tsis txhob ntxiv qhov thib ob extruder nkaus xwb raws li kev hloov kho dav dav.
Cov ntaub ntawv khoom dab tsi Kinggle xav tau rau 60L lub tswv yim tshuab?
Xa cov khoom kos duab lossis duab, qhov ntev, tiav thiab tag nrho cov khoom, qib resin, phab ntsa qauv, thickness yuav tsum, tso zis lub hom phiaj thiab kev xeem ua haujlwm. Ntxiv cov ntsiab lus pwm thiab cov khoom siv hluav taws xob hauv lub Hoobkas thaum muaj. Cov ntaub ntawv no cia lub tshuab, tuag lub taub hau, pwm thiab kev sim siv cov khoom siv tib yam.
Yuav siv zog npaum li cas piv rau ntawm ob tus qauv?
Ntsuas txhua tus qauv thaum ua cov khoom lees txais tib yam raws li qhov sib npaug. Cov ntaub ntawv tshuab kWh, lees txais cov zis, extruded huab hwm coj thiab suav nrog cov pab cuam los ntawm tib lub sijhawm lub qhov rais. Tsis txhob sib piv cov kev sib txuas ntawm lub cev muaj zog los yog lub voj voog qhuav xws li cov khoom siv hluav taws xob.
Xa cov khoom ua ntej xaiv tus qauv
Qhia tawm cov duab kos, resin, tag nrho parison pawg, cov qauv phab ntsa, cov ntaub ntawv pwm, txais cov khoom tsim tawm thiab cov khoom siv hauv tsev. Kinggle tuaj yeem paub meej tias KGB90A, KGB90AP lossis lwm lub platform haum rau qhov project.
