1214 Shipping Pallet Ua Tshuab

Model:KGS150A

Qhia KGS150A Qhov twg yog qhov txhim khu kev qha 1214 shipping pallet ua tshuab tsim rau tshuab mouldics pallit cov ntawv thov. Ua rau lub pallet loj rau Extrusion tshuab moulding tshuab xav tau, nws ua kom ntev-kav ntev thiab nqi txuag koj tuaj yeem suav tau.

Ntim: 2000LQhov hnyav: 45T

Xa lus nug

Product Description

KGS150A yog qhov precision-engineered 1214 shipping pallet ua tshuab, Cov yam ntxwv tseem ceeb suav nrog cov qauv tsim qauv rau ntau qhov loj me pallet sib xyaw, servo-tsav tshuab rau kev txuag hluav taws xob, neeg siv-phooj ywg zoo hmi (Tib neeg lub tshuab interface) rau kev ua haujlwm yooj yim, thiab hloov pauv sai Lub peev xwm los txhim kho cov khoom lag luam. Cov tiav lawm pallets yog dav siv hauv kev logistics, chaw ua yeeb yam, ua zaub mov, thiab kev tsim khoom lag luam, Kev muab cov txiaj ntsig zoo xws li kev tsim kho khaub ncaws hnav, corrosion kuj, thiab cuam tshuam tsis kam, ua rau lawv txoj kev hloov kho hauv eco-phooj ywg rau Tsoos ntoo tsoos ntoo.

Cov lus qhia

muaj pes tsawg tus lej	Khoom HDPE ...	PWM ZAJ ROJ KHEEJ (PEB KHEEJ KHEEJ)
muaj pes tsawg tus lej	Khoom HDPE ...	TSHUAB qauv: KGS150A
Cov lus qhia
1	Max Ntim Peev Xwm	2000 L
2	Tso Tawm (Lub voj voog qhuav)	300 PC / hr
3	Tshuab Dimension (L × W × h)	8.5 m × 3.8 m 6 m
4	Tshuab qhov hnyav	45 t
Clamping chav tsev
1	Clamping yuam	1800 KN
2	Pwm Platen Loj (W × h)	1600 hli X 1900 hli
3	Daim phiaj qhib Toke	800 mm - 2200 hli
4	Platen Tsiv stroke	1000 mm
5	Max Pwm Loj (W × h)	1400 hli × 1900 hli
6	Pwm Thickness	830 hli - 1150 hli
Hwjchim
1	Servooil twj tso kua mis muaj zog	25 kw
2	SERVO TWJ TSO KUA MIS	200 l / min
3	Hau pliaj	0.8 MPa
4	Kev Siv Cua Cua	2 m² / mi
5	Cua txias dej siab	0.3 MPa
6	Kev Siv Dej	120 l / min
7	Qhov nruab nrab hluav taws xob siv	110 kw -150 kw
Extruder Chav
1	Ntsia Hlau taub	150 hli
2	Ntsia hlau L / d piv	30 l / d
3	Melting capacit rau HDPE	500 KG / HR -600 KG / HR
4	Cov naj npawb ntawm thaj chaw ua cua sov	5 Cheeb Tsam
5	NTSIA HLUB cua kub	32.5 KW
6	Ntsia hlau fanpower	0.6 kw
7	Extruder Lub Zog Muaj Zog	160 (180) kw
Tuag Lub Taub Hau
1	Cov naj npawb ntawm cov hluav taws xob	6 cheeb tsam
2	Cua sov fais fab	39 kw
3	Maxdie-tus pin inch	800 (950) hli
4	Accumulator muaj peev xwm	45 (60) l
5	(PE) Tsoos Kev Nyuaj Siab	33 (45) kg

Nta thiab Qhov Zoo

Hollow cov qauv tsim los ntawm tshuab moulding tsim muaj peev xwm tshwj xeeb thauj khoom muaj peev xwm xws li cov saw hlau hnyav thiab kev lag luam hnyav.
Kev hloov kho kom haum rau kev sib txawv ntau thiab tsawg, cov duab ("ceg tawv)
100% siv rov qab cov ntaub ntawv raw, xoom ua kom tsis muaj teeb meem thaum lub sijhawm tsim khoom, thiab ib lub neej ntau dua li kev noj thiab haus cov hneev taw.
