10l Ntoos Tshuab Tshuab Molding Tshuab

Model:KGB70A

KGB70A yog ib qho ntau ntau yam 10l accumul ntaub tshuab moulding tshuab tsim rau max 15-liter lub raj mis tshuab moulding. Raws li ib tug coj dej fwj tshuab chaw tsim tshuaj paus, peb muab cov kev daws teeb meem kom tau raws li cov neeg siv khoom. Lub tshuab tsis yog tsuas yog rau cov dej fwj, tshuaj tua kab, thiab siv tshuaj ntim txhua hnub, khoom siv tshwj xeeb. Lub tshuab no sib ntsib ntau yam kev xav tau.

Ntim: 20lNyhav: 7.8T

Xa lus nug

Product Description Specification Application

KGB70A 10L NOJ TSHUAB Cov Tshuab Moulding yog qhov chaw qhib thiab kaw qauv, uas adopts ob npaug rub tawm sod synchronous clamping me ntsis, roj Lub tog raj kheej ncaj ncaj xauv cov pwm pwm, actaws kheej kheej lub tog raj kheej tuag taub hau. Hydralic servo system tswj, Cov lus teb ceev ceev thiab txuag hluav taws xob.
Ntau suite rau cov qauv tshwj xeeb cov khoom lag luam, muaj peev xwm Tswj cov duab thiab tuab ntau qhov tseeb.

Nta thiab Qhov Zoo

Tus qauv no yog qhov chaw qhib thiab kaw cov pwm, siv ob npaug rau ob npaug synchronous zaj duab xis kaw kaw lub puab tsaig pwm
● Cia lub tog raj kheej tuag lub taub hau series
● Feem ntau cov ntim 0L
Tsim kom haum rau cov dej fwj, tshuaj tua kab, thiab ntim khoom txhua hnub, thiab lwm yam.
● Cov yam ntxwv txawv yog tias nws raug tswj hwm los ntawm ib hydraulic servo system kom ua tiav ceev kev ua teb thiab muaj zog ua haujlwm.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
